Hexagon screw 955525
| No. | Part Name | Part Number | Qty | Description |
| 1 | Cylinder block | 1545210 | 1 | |
| 3 | Pin | 422426 | 1 | |
| 4 | Flange screw | 422067 | 14 | |
| 5 | Bushing | 422076 | 1 | |
| 6 | Bushing | 422077 | 1 | |
| 7 | Bushing | 422078 | 1 | |
| 8 | Bushing | 422079 | 1 | |
| 9 | Bushing | 422080 | 1 | |
| 10 | Bushing | 422081 | 1 | |
| 11 | Bushing | 422082 | 1 | |
| 12 | Plug | 467367 | 5 | |
| 13 | Gasket | 469328 | 6 | |
| 14 | Plug | 942734 | 1 | |
| 15 | Plug | 467366 | 1 | |
| 16 | Gasket | 468463 | 1 | |
| 17 | Plug | 422369 | 7 | |
| 18 | Plug | 180761 | 1 | |
| 19 | Gasket | 11996 | 1 | |
| 20 | Cap plug | 955083 | 3 | |
| 22 | Plug | 16318 | 3 | |
| 23 | Gasket | 907132 | 3 | |
| 24 | Plug | 190798 | 1 | |
| 25 | Gasket | 18818 | 1 | |
| 30 | Plug | 952075 | 1 | |
| 31 | Plug | 952077 | 1 | |
| 32 | Reduction nipple | 190130 | 1 | |
| 33 | Drain cock | 820436 | 1 | |
| 34 | Drain tube | 821889 | 1 | |
| 35 | Fitting nut | 954357 | 1 | |
| 36 | Fitting | 954365 | 1 | |
| 37 | Clamp | 942400 | 1 | |
| 38 | Hexagon screw | 940133 | 1 | |
| 39 | Washer | 940097 | 1 | |
| 40 | Inspection cover | 423120 | 2 | |
| 41 | Inspection cover | 423121 | 1 | |
| 42 | Crankcase ventilatio | 824365 | 1 | |
| 43 | Splash plate | 422542 | 1 | |
| 44 | Splash plate | 824369 | 1 | |
| 45 | Gasket | 467409 | 3 | |
| 46 | Gasket | 824343 | 1 | |
| 47 | Shoulder screw | 422541 | 6 | |
| 48 | Screw | 823742 | 2 | |
| 49 | Hexagon screw | 940100 | 2 | |
| 50 | Spring washer | 941906 | 2 | |
| 52 | Hose attachment | 815239 | 1 | |
| 53 | Tube | 837214 | 1 | |
| 54 | Oil pipe | 842135 | 1 | |
| 55 | Elbow nipple | 954342 | 2 | |
| 56 | Nipple | 942347 | 1 | |
| 57 | Gasket | 957181 | 1 | |
| 58 | Attaching clamp | 18301 | 1 | |
| 59 | Hexagon screw | 955523 | 1 | |
| 60 | Spring washer | 941907 | 1 | |
| 61 | Oil filler pipe | 821792 | 1 | |
| 62 | Retainer | 820964 | 1 | |
| 63 | O-ring | 925057 | 1 | |
| 64 | Hexagon screw | 955282 | 1 | |
| 65 | Lock nut | 963105 | 1 | |
| 66 | Washer | 955893 | 1 | |
| 67 | Breather cap | 407173 | 1 | |
| 68 | Gasket | 940096 | 1 | |
| 69 | Tube | 467090 | 1 | |
| 70 | Sealing ring | 421158 | 1 | |
| 71 | Hexagon screw | 940113 | 2 | |
| 72 | Spring washer | 941907 | 2 | |
| 74 | Hexagon screw | 955561 | 2 | |
| 75 | Spring washer | 940280 | 2 | |
| 76 | Nipple | 947807 | 1 | |
| 77 | Gasket | 957175 | 2 | |
| 78 | Hollow screw | 74040 | 1 | |
| 79 | Housing | 820837 | 1 | |
| 80 | Tube | 820838 | 1 | |
| 81 | Bowl | 820839 | 1 | |
| 82 | Strainer | 820842 | 2 | |
| 83 | Spacer ring | 820843 | 1 | |
| 84 | Sealing ring | 421158 | 2 | |
| 85 | Screw | 823371 | 1 | |
| 86 | Sealing ring | 424342 | 1 | |
| 87 | Sealing ring | 420269 | 1 | |
| 88 | Attaching bracket | 820847 | 1 | |
| 89 | Hexagon screw | 955525 | 2 | |
| 90 | Spring washer | 941907 | 2 | |
| 91 | Hexagon screw | 955534 | 1 | |
| 92 | Spring washer | 942336 | 1 | |
| 93 | Nipple | 954335 | 1 | |
| 94 | Oil pipe | 820946 | 1 | |
| 95 | Pipe elbow | 820841 | 1 | |
| 96 | Elbow nipple | 954342 | 1 | |
| 97 | Nipple | 942347 | 1 | |
| 98 | Gasket | 957182 | 1 | |
| 99 | Plug | 190798 | 1 | |
| 100 | Gasket | 957182 | 1 | |
| 12A | Plug | 821335 | 1 | |
| 12B | Plug | 952075 | 1 | |
| 15A | Nipple | 422550 | 1 |
| Item | Part Name | Part No. |
| 89 | Hexagon screw 955525 | 955525 |
| Details | |
| Engine model | D100A D100A, D100B D100B D100B, TD100A D100BHC, D100BRC D100BHC, TD100AHC D120A D120A, TD120A D42A D70B D70B, TD70B D70CHC D70CHC, D70CRC, TD70CHC, TD70CRC D70CHC, TD70CHC D70CRC DH10A, THD102KD, THD102KB TAD1030G TAD1030GE, TAD1031GE, TAD1032GE TAD1030GE, TAD1031GE, TAD1032GE, TAD1031G TAD1030P TAD1030V TAD1030V, TWD1031VE TAD120AHC TAD120BHC TAD120CHC TAD121CHC TAD1230G, TAD1231GE, TAD1232GE TAD1230G, TD1210G, TWD1210G, TWD1211G TAD1230G, TD1210G, TWD1210G, TWD1211G, TAD1231GE, TAD1232GE TAD1230P TAD1230P, TD121GP-87, TWD1210P, TWD1211P TAD1230P, TD121GP-87, TWD1210P, TWD1211P, TD1210G, TWD1210G, TWD1211G TAD1230V TAD1231GE, TAD1232GE TAD1631G, TAD1631GE TD100A TD100ARC TD100CHC TD100CRC TD100G TD100G, TD100G-85, TID100K TD100G, TD100HP-87, TID100K TD100G-85 TD100G-87 TD100G-87, TD1030ME TD100G-87, TD1030ME, TWD1030ME TD100G-87, TD1030VE TD100G-87, TD1030VE, TAD1030V, TWD1031VE, TAD1030VE TD100G-87, TID100K-87 TD100GG TD100GG-85 TD100GG-87 TD100GP TD100GP-85 TD100HP-87 TD100HPB-87 TD1010G, TWD1010G TD1030ME, TWD1030ME TD1030VE TD1030VE, TWD1031VE TD120A TD120AHC TD120ARC TD120BHC TD120BRC TD120C TD120G TD120G, TD120GG TD120GG TD120HP-86 TD120HP-86, TD121G, TD121GG, TD121GG-86, TD121GGP, TID121K, TID121KG, TID121KP, TID121KGP, TID121LG, TID121LGP, TID121LP TD120HP-86, TD121G, TID121K, TID121L-87 TD120HPP TD1210G, TWD1210G, TWD1211G TD121CHC TD121CHC, TD121CRC TD121CRC TD121G TD121G-87 TD121G-87, TD121GG-87, TD121GGP-87, TD121GPB-87 TD121G-87, TWD1210V, TWD1211V, TAD1230V, TWD1230VE TD121G-87, TWD1210V, TWD1211V, TAD1230V, TWD1230VE, TWD1231VE TD121G-87, TWD1230VE, TWD1231VE TD121GG TD121GG-86 TD121GG-87 TD121GGP-87 TD121GP-87 TD121GP-87, TWD1211P TD121GPB-87 TD164KAE TD45B TD60A TD60A, TD60B TD60B TD60D TD60D, TID60D TD60D-83 TD610G, TWD610G, TD710G, TWD710G, TAD730G, TWD740GE, TAD740GE, TAD741GE TD610M, TD630ME, TWD630ME, TD730ME, TWD730ME, TWD731ME TD610V, TWD610V, TD630VE, TWD630VE, TD640VE TD61A, TD61AW, TD61ACE, TD61AG, TD61AGP, TD61AP, TD61APB, TID61AG, TD71A, TD71AW, TD71ACE, TD71AG, TD71AGP, TD71AP, TD71APB, TID71A, TID71AG, TID71AGP, TID71AP, TID71APB, TID61AGP TD70B TD70CHC TD70CRC TD70G TD70G, TD70G-83, TD70GPP, TD70GPP-83, TID70G, TID70GPP, TID70GG TD70G-83 TD71A, TID71A, TWD710V, TD730VE, TWD731VE, TAD730V, TWD740VE TID100K TID100K-87 TID100KG TID100KG-87 TID100KGP-87 TID100KP TID100KP-87 TID100KPB-87 TID120FG TID120HPP TID121FG TID121K, TID121KG, TID121KP TID121K-87 TID121KG, TID121KGP, TID121LG, TID121LGP TID121KG-87 TID121KGP TID121KP-87, TID121KPB-87 TID121L-87 TID121LG TID121LG-87 TID121LGP-87 TID121LP TID121LP-87, TID121LPB-87 TID162AG, TID162AGP, TID162AP, TID162APB TID60D TID60DG TID70G TWD1010G TWD1030ME TWD1031VE TWD1210G, TWD1211G TWD1210P TWD1210P, TWD1211P TWD1210P, TWD1211P, TWD1210G, TWD1211G TWD1210V, TWD1211V, TAD1230V TWD1210V, TWD1211V, TWD1230VE TWD1210V, TWD1211V, TWD1230VE, TWD1231VE TWD1230ME TWD1230VE TWD1231VE TWD1620G TWD1630G TWD1630P TWD1630V TWD610P, TWD610PB, TWD710P, TWD710PB, TAD730P |
| Application | Air Compressor Air Compressor Knorr LP48 ESS Air Compressor Knorr LP4967 Air Compressor Wabco 704 AIR FILTER AND INSTALLATION COMPONENTS Alternator and Installation Components, MO-XXXXX/30307: A Alternator and Installation Components, MO-XXXXX/30307: B Alternator and Installation Components, MO-XXXXX/30307: C Charging Relay and Installation Components Clutch with Installation Components Clutch with Installation Components: A Clutch with Installation Components: B Cooling Water Filter Coupling for Fuel Injection Pump with Cover Coupling for Fuel Injection Pump with Cover, SN-2120187412 Coupling for Injection Pump with Cover, Earlier Production Cylinder Block Cylinder Block and Related Parts: B Cylinder Block: A Cylinder Block: B Drive Device for Fuel Injection Pump: A Drive Device for Fuel Injection Pump: B DRIVE DEVICE, FUEL INJECTION PUMP Drive Device, Fuel Injection Pump: A Drive Device, Fuel Injection Pump: B Drive Device, Fuel Injection Pump: C Drive Device, Fuel Injection Pump: D Electrical Oil Bilge Pump and Installation Components ELECTRICAL SYSTEM AND INSTRUMENT Electrical System and Instrument: A Electrical System and Instrument: B Electronic Speed Control External Cooling System, Induction Manifold and Intercooler Fuel Injection Pump and Fuel Inj.Pump Coupling. Spec.867578 Fuel Injection Pump Coupling Fuel Injection Pump Coupling. Fuel Injection Pump Coupling: A Fuel Injection Pump Coupling: B Fuel Injection Pump Coupling: C Gear Box 254603 and Installation Components Gear Box R60 and Installation Components Alt: 254454 Gear Box R60 and Installation Components Alt: 254458 HEAT EXCHANGER AND THERMOSTAT WITH INSTALLATION COMPONENTS Housing-oil Filter INDUCTION AND EXHAUST SYSTEM Induction Manifold and Installation Components Induction Manifold and Intercooler Inlet Manifold and Aftercooler Inlet Manifold and Installation Components Inlet Manifold with Intercooler, High Mounted Turbo Inlet Manifold with Intercooler, High Mounted Turbo: A Inlet Manifold with Intercooler, High Mounted Turbo: B Inlet Manifold with Intercooler, low mounted Turbo Inlet Manifold with Intercooler, Low Mounted Turbo: A Inlet Manifold with Intercooler, Low Mounted Turbo: B Lubricating Oil Tank LUBRICATING SYSTEM Lubricating System Standard Model: A Lubricating System Standard Model: B Lubricating System Standard Model: C Lubricating System, 40° Inclination Lubricating System, Angle of Inclination 10° Lubricating System, Angle of Inclination 40° Lubricating System, Angle of Inclination 40°: A Lubricating System, Angle of Inclination 40°: B Lubricating System, Classed Engine Lubricating System, Classed Engine: A Lubricating System, Earlier Production Lubricating System, Later Production Lubricating System, Later Production: A Lubricating System, Later Production: B Lubricating System, Spec.9755, 9762, 9803, 9946, 867017, 867024,867045 Lubricating System, Standard Model Lubricating System, Standard Model: A Lubricating System, Standard Model: B Lubricating System, Standard: A Lubricating System, Standard: B Lubricating System, Standard: C Lubricating System, Standard: TD100GGP-87 Lubricating System: A Lubricating System: B Lubricating System: C Lubricating System: D LUBRICATING SYSTEM: TID121FP Oil Bilge Pump and Installation Components Oil Cooler Oil Cooler and Installation Components Oil Cooler with Installation Components Oil Cooler, Side Mounted Oil Filter and Installation Components Oil Filter Housing OIL SUMP PUMP AND INSTALLATION COMPONENTS Oil Sump Pump and Installation Components: A RADIATOR AND FAN WITH INST.COMPS SPEC.867113, 867131, 16053, 867638 Radiator and Fan with Installation Components RADIATOR AND FAN WITH INSTALLATION COMPONENTS, SPEC.9969 Radiator and Installation Components: A Radiator and Installation Components: B Repair Kits Repair Kits: A Repair Kits: B Repair Kits: C Repair Kits: TD100-87 Repair Kits: TID100-87 Thermostat and Water Pump with Installation Components Thermostat and Water Pump with Installation Components: A Thermostat and Water Pump with Installation Components: B Thermostat and Water Pump with Installation Components: C Thermostat and Water Pump with Installation Components: D THERMOSTAT AND WATER PUMP WITH INSTALLATION COMPONENTS: TID121FP Thermostat Housing Timing Gear Casing and Gear: A Timing Gear Casing and Gear: B Timing Gear Casing and Gear: C Timing Gear Casing and Gear: D Timing Gear Casing and Gears Timing Gear Casing and Gears: A Timing Gear Casing and Gears: B TIMING GEAR CASING AND GEARS: C Turbo and Installation Components Turbo and Installation Components, Low Mounted TURBO AND INSTALLATION COMPONENTS, LOW MOUNTED: A TURBO AND INSTALLATION COMPONENTS, LOW MOUNTED: B Turbo and Installation Components: A Turbo and Installation Components: B Water Filter and Installation Components Water Pump Water Pump and Thermostat Housing Water Pump and Thermostat Housing, Earlier Prod. Water Pump and Thermostat Housing, Later Prod.: A Water Pump and Thermostat Housing, Later Prod.: B Water Pump and Thermostat Housing, Later Prod.: C Water Pump and Thermostat SN-XXXXXXXXXX/21158 Water Pump and Thermostat SNXXXXXXXXXX/211549-: A Water Pump and Thermostat SNXXXXXXXXXX/211549-: B Water Pump and Thermostat: A Water Pump and Thermostat: B Water Pump, Components Water Pump, Thermostat and Fan Bearing |
| Specification | |
| Descriptions | ÅKERMAN. (956570) 1pc 829520 consist of 4 shims. D70B spec.867057,867058, (MOXXXXX/15607-,see lubricating system standard model),867059,867063,867221,867283.TD70B spec.867065 alt. For 815261. L = 25 MM L=25mm MO-XXXX/238478 MO20782/XXXXX- Replaced by 1pc 1544097. Spec. 867113. alt spec. 9969. Used when separate exhaust outlet and water intake is mounted. |
