Hose clamp 978402
| No. | Part Name | Part Number | Qty | Description |
| 1 | Turbocharger | 3801421 | 1 | |
| 2 | Plane gasket | 20784537 | 1 | |
| 3 | Spacer sleeve | 478344 | 4 | |
| 4 | Stud | 20579303 | 4 | (977299) |
| 5 | Flange nut | 1543499 | 4 | |
| 6 | Oil feed hose | 11158484 | 1 | |
| 7 | Flange | 8192268 | 1 | |
| 8 | O-ring | 976971 | 1 | |
| 9 | Flange screw | 984737 | 2 | |
| 10 | Gasket | 22206133 | 1 | |
| 11 | Oil return pipe | 11158044 | 1 | |
| 11 | Oil return pipe | 15160855 | 1 | Replaced by 22929549 |
| 11 | Return pipe | 22929549 | 1 | |
| 12 | Pipe flange | 469543 | 1 | |
| 13 | Rubber moulding | 469601 | 1 | |
| 14 | Connector | 8148729 | 1 | |
| 15 | Gasket | 470993 | 1 | (420423) |
| 16 | Flange screw | 984738 | 2 | |
| 17 | Sealing ring | 1547255 | 1 | |
| 18 | Connecting pipe | 21159129 | 1 | For upgrade to new solution,see section 41232,use pos 3-5,18-29 and 45 |
| 19 | V-clamp | 3886542 | 1 | |
| 20 | Sealing ring | 1675066 | 1 | |
| 21 | Bracket | 21205043 | 1 | For upgrade to new solution,see section 41232,use pos 3-5,18-29 and 45 |
| 22 | Flange screw | 984734 | 1 | |
| 23 | Lock brace | 1546531 | 1 | |
| 24 | Flange screw | 984733 | 1 | |
| 25 | Flange screw | 984752 | 2 | |
| 26 | Tube | 20711293 | 1 | |
| 27 | Cable tie | 983472 | 1 | For cable to unit injectors. |
| 28 | Fuel hose | 1266870 | 1 | |
| 29 | Hose clamp | 975269 | 4 | |
| 30 | Hose clamp | 978402 | 2 | |
| 31 | Clamp | 942400 | 3 | |
| 32 | Flange screw | 984733 | 3 | |
| 33 | Pipe | 21154124 | 1 | |
| 34 | Retainer | 984937 | 1 | |
| 35 | Fuel hose | 1266870 | 1 | |
| 36 | Retainer | 21045811 | 1 | |
| 38 | Solenoid valve | 3819161 | 1 | |
| 39 | Six point socket scr | 969407 | 2 | |
| 40 | Gasket | 23029715 | 1 | Included in Turbocharger |
| Item | Part Name | Part No. |
| 30 | Hose clamp 978402 | 978402 |
| Details | |
| Engine model | TAD1344GE, TAD1345GE, TAD1353GE TAD1345VE TAD1360VE TAD1360VE, TAD1361VE, TAD1362VE, TAD1363VE, TAD1364VE, TAD1365VE TAD1361VE TAD1363VE TAD1660VE, TAD1661VE, TAD1662VE, TAD1640VE-B, TAD1641VE-B, TAD1642VE-B |
| Application | Turbocharger |
