Injection pump 864818
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Injection pump |
864818 |
1 |
|
| 1 |
Injection pump |
3803707 |
1 |
Std |
| 3 |
Feed pump |
244825 |
1 |
|
| 4 |
Gasket |
863370 |
1 |
|
| 5 |
Control sleeve |
240782 |
6 |
|
| 6 |
Spring disc |
239984 |
6 |
|
| 7 |
Compression spring |
244731 |
6 |
(847277) |
| 8 |
Spring disc |
244685 |
6 |
(6211952) |
| 9 |
Gasket |
18836 |
6 |
|
| 10 |
Gasket |
969011 |
1 |
|
| 11 |
Overflow valve |
3825154 |
1 |
|
| 12 |
Gasket |
240017 |
1 |
Spec.867473 alt |
| 13 |
Key |
35168 |
1 |
|
| 14 |
Camshaft seal |
864299 |
1 |
|
| 15 |
O-ring |
243299 |
1 |
|
| 16 |
Gasket |
1699581 |
1 |
|
| 17 |
Gasket |
969011 |
2 |
|
| 18 |
Retainer |
244636 |
6 |
|
| 19 |
Peg |
240971 |
6 |
|
| 20 |
O-ring |
240001 |
6 |
|
| 21 |
Compression spring |
240969 |
6 |
|
| 22 |
Sealing washer |
239993 |
6 |
|
| 23 |
Delivery valve |
849033 |
6 |
|
| 24 |
Pump element |
846576 |
6 |
|
| 25 |
O-ring |
240422 |
12 |
|
| 27 |
Repair kit |
845240 |
1 |
See group 10A |
| Item |
Part Name |
Part No. |
| 1 |
Injection pump 864818 |
864818 |
| Details |
| Application |
Fuel Injection Pump, Components |
