Nut plate 414735
| No. | Part Name | Part Number | Qty | Description |
| 1 | Injection pump | 842738 | 1 | |
| 2 | Bracket | 468558 | 1 | |
| 3 | Guide sleeve | 423161 | 2 | |
| 4 | Guide sleeve | 417588 | 1 | |
| 5 | Hexagon screw | 955566 | 4 | AQ115A MOXXXX/86909-., Repl by 1pc 840539 bracket (8 holes), 9PCS 941907 6PCS 9552 97, 2pcs 955298., L=64mm |
| 6 | Spring washer | 940280 | 4 | |
| 7 | Hexagon screw | 940156 | 4 | |
| 8 | Washer | 190509 | 4 | |
| 9 | Pressure equalizer | 466398 | 1 | |
| 10 | Gasket | 18671 | 1 | |
| 12 | Lever | 821134 | 1 | |
| 13 | Spring | 239056 | 1 | Replaced by 837364. |
| 14 | Cover | 239059 | 1 | Replaced by 837364 |
| 15 | Washer | 120265 | 1 | |
| 16 | Hexagon screw | 955637 | 1 | |
| 17 | Spring washer | 941906 | 1 | |
| 18 | Filter housing | 241672 | 1 | Replaced by 1 PC 843512,1 ST 191026., Classed engine,not included in fuel feed pump. |
| 19 | Bracket | 844024 | 1 | |
| 20 | Plug | 960630 | 3 | Replaced by 1 PC 843512,1 ST 191026. |
| 21 | Gasket | 18671 | 3 | |
| 22 | Hexagon screw | 940114 | 2 | |
| 23 | Washer | 960142 | 2 | Replaced by 1 PC 843512,1 ST 191026. |
| 24 | Spring washer | 942336 | 2 | |
| 25 | Hexagon nut | 955827 | 2 | AQ115A MOXXXX/86909-., Repl by 1pc 840539 bracket (8 holes), 9PCS 941907 6PCS 9552 97, 2pcs 955298. |
| 26 | Hexagon screw | 940162 | 1 | MO-XXXXX/105194 |
| 26 | Hexagon screw | 955536 | 1 | AQ115A MOXXXX/86909-., Repl by 1pc 840539 bracket (8 holes), 9PCS 941907 6PCS 9552 97, 2pcs 955298., Late type |
| 27 | Spring washer | 942336 | 2 | |
| 28 | Fuel pipe | 468480 | 1 | |
| 29 | Tube | 468481 | 1 | |
| 30 | Hollow screw | 25167 | 4 | |
| 31 | Gasket | 18671 | 8 | |
| 32 | Attaching clamp | 404279 | 2 | D70B spec. 867054, 867055, 867061, 867062, 867063, 867132, TD70B spec. 867065. |
| 33 | Cross recessed screw | 950047 | 1 | |
| 34 | Hexagon nut | 955825 | 1 | Late type |
| 35 | Feed line | 423393 | 1 | |
| 36 | Hollow screw | 48634 | 1 | |
| 37 | Gasket | 957173 | 2 | |
| 38 | Hollow screw | 942081 | 1 | |
| 39 | Gasket | 11994 | 1 | |
| 40 | Gasket | 18666 | 1 | |
| 41 | Fuel pipe | 842656 | 1 | |
| 42 | Hollow screw | 25167 | 1 | |
| 43 | Gasket | 18671 | 2 | |
| 44 | Return pipe | 422246 | 1 | |
| 45 | Hollow screw | 25167 | 1 | |
| 46 | Gasket | 18671 | 3 | |
| 47 | Hollow screw | 954394 | 1 | |
| 48 | Gasket | 11998 | 1 | |
| 49 | Fuel pipe | 842657 | 1 | |
| 50 | Anchorage | 821625 | 1 | |
| 51 | Attaching clamp | 404279 | 1 | D70B spec. 867054, 867055, 867061, 867062, 867063, 867132, TD70B spec. 867065. |
| 52 | Cross recessed screw | 950048 | 1 | D70B spec. 867054, 867055, 867061, 867062, 867063, 867132, TD70B spec. 867065. |
| 53 | Washer | 955893 | 1 | |
| 54 | Hexagon nut | 955825 | 1 | Late type |
| 55 | Attaching clamp | 404279 | 2 | D70B spec. 867054, 867055, 867061, 867062, 867063, 867132, TD70B spec. 867065. |
| 56 | Cross recessed screw | 950047 | 1 | |
| 57 | Hexagon nut | 955825 | 1 | Late type |
| 58 | Leak-off line | 845326 | 1 | (844893) |
| 59 | Overflow valve | 35096 | 1 | |
| 60 | Gasket | 18671 | 1 | |
| 61 | Gasket | 18671 | 2 | |
| 62 | Hollow screw | 16496 | 1 | |
| 63 | Hollow screw | 74033 | 1 | |
| 64 | Gasket, oil pipe | 946729 | 2 | |
| 65 | Injector | 468627 | 6 | |
| 66 | Sealing ring | 468210 | 6 | |
| 67 | Stud | 944189 | 12 | |
| 68 | Nut | 417110 | 12 | |
| 69 | Leak-off line | 822564 | 1 | MO-XXXXX/1495. |
| 70 | Hollow screw | 74034 | 1 | D42A PP spec. 16053, 867638. |
| 71 | Gasket | 947620 | 3 | (233321) |
| 72 | Hollow screw | 74033 | 5 | |
| 73 | Gasket, oil pipe | 946729 | 10 | |
| 74 | Clamp | 121563 | 1 | |
| 75 | Cross recessed screw | 950045 | 1 | |
| 76 | Spring washer | 941906 | 1 | |
| 77 | Delivery pipe | 468600 | 1 | |
| 78 | Delivery pipe | 468601 | 1 | |
| 79 | Delivery pipe | 468602 | 1 | |
| 80 | Delivery pipe | 423515 | 1 | |
| 81 | Delivery pipe | 423516 | 1 | |
| 82 | Delivery pipe | 423517 | 1 | |
| 83 | Attaching clamp | 414345 | 8 | |
| 84 | Attaching clamp | 414344 | 8 | |
| 85 | Nut plate | 414736 | 1 | |
| 86 | Bracket | 468005 | 3 | |
| 87 | Hexagon screw | 940100 | 3 | |
| 88 | Spring washer | 941906 | 3 | |
| 89 | Attaching clamp | 414347 | 4 | |
| 90 | Attaching clamp | 414346 | 4 | |
| 91 | Nut plate | 414735 | 2 | |
| 92 | Hexagon screw | 955249 | 12 | |
| 93 | Fuel hose | 845450 | 2 | (880618) |
| 94 | Fitting nut | 956983 | 4 | |
| 95 | Ferrule | 956969 | 4 |
| Item | Part Name | Part No. |
| 91 | Nut plate 414735 | 414735 |
| Details | |
| Engine model | D120A D70B TAD120AHC TAD120BHC TAD120CHC TAD121CHC TD120A TD120AHC TD120ARC TD120BHC TD120BRC TD120C TD120G TD120GG TD121CHC TD121CRC TD60A TD60B TD70B TID120FG |
| Application | Classed Fuel System: A Classed Fuel System: B Fuel System Fuel System MO-46196/XXXXX: A Fuel System MO-46196/XXXXX: B Fuel System MO46197/XXXXX-: A Fuel System MO46197/XXXXX-: B Fuel System, Classed Engine, Spec.867053, MO-46196/XXXXX Fuel System, Classed Engine, Spec.867053, MO46197/XXXXX- Fuel System, Classed Engine, Spec.867117 Fuel System, Standard Model: A Fuel System, Standard Model: B Fuel System: A Fuel System: B Fuel System: C |
| Specification | |
| Descriptions | EARLY TYPE MO-XXXXX |
