O-ring 942089
| No. | Part Name | Part Number | Qty | Description |
| 2 | Lock washer | 383992 | 1 | |
| 3 | Piston | 382345 | 1 | |
| 4 | O-ring | 942089 | 1 | Replaced by 1pc 382913 cable and 1pc 267345 lever. |
| 5 | Seal | 943015 | 1 | T.O.M gear BOX type R51 (254602,254603) NR.4989., Replaced by 1pc 382913 cable and 1pc 267345 lever., Early type |
| 5 | Piston seal | 945520 | 1 | Replaced by 1pc 382913 cable and 1pc 267345 lever., Late type |
| 6 | Cover | 382142 | 1 | |
| 7 | O-ring | 941900 | 1 | Replaced by 1pc 382913 cable and 1pc 267345 lever |
| 8 | Air filter | 382143 | 1 | |
| 9 | O-ring | 955975 | 1 | Replaced by 1pc 382913 cable and 1pc 267345 lever. |
| 10 | O-ring | 955999 | 1 | Replaced by 1pc 382913 cable and 1pc 267345 lever. |
| 11 | Hexagon screw | 955543 | 2 | |
| 12 | Spring washer | 942336 | 2 | |
| 14 | Valve housing | 382076 | 1 | |
| 15 | Valve peg | 382077 | 1 | |
| 16 | Compression spring | 382078 | 1 | Replaced by 1pc 1527192 gear and 1pc 1527202 sender |
| 17 | O-ring | 947776 | 1 | Replaced by 1pc 1527192 gear and 1pc 1527202 sender., (925083) |
| 18 | Valve disc | 1526531 | 1 | Replaced by 1pc 1527192 gear and 1pc 1527202 sender., (382079) |
| 19 | Spring | 382081 | 1 | Replaced by 1pc 1527192 gear and 1pc 1527202 sender |
| 20 | O-ring | 947776 | 1 | Replaced by 1pc 1527192 gear and 1pc 1527202 sender., (925083) |
| 21 | Cover | 266446 | 1 | |
| 22 | Air filter | 382357 | 1 | Replaced by 1pc 1527192 gear and 1pc 1527202 sender |
| 23 | O-ring | 925053 | 2 | |
| 24 | Cross recessed screw | 950021 | 2 | |
| 25 | Repair kit, operating cylinder | 273081 | 1 | |
| 25 | Repair kit, lock valve | 273082 | 1 | |
| 25 | Toothed washer | 955946 | 2 | AQ290A MO 20460-. |
| Item | Part Name | Part No. |
| 4 | O-ring 942089 | 942089 |
| Details | |
| Engine model | D100A D100B D120A D42A D70B D70B, TD70B TAD1030P TAD1230G TAD1230P TAD1230V TD100A TD100G-87, TD1030ME, TWD1030ME TD100G-87, TD1030VE, TAD1030V, TWD1031VE, TAD1030VE TD120A TD1210G, TWD1210G, TWD1211G, TAD1231GE, TAD1232GE TD121G-87, TWD1210V, TWD1211V, TWD1230VE, TWD1231VE TD45B TD70B TWD1210P, TWD1211P TWD1230ME |
| Application | Belt Tensioner Device Belt Tensioner Device, Late Design: B Belt Tensioner Device, Late Design: TD121G -87 Belt Transmission and Belt Tensioner Device: A Belt Transmission and Belt Tensioner Device: B Gear Box 254420, 254424, 254454, 254458 Gear Box 254602, 254603 Operating Cylinder, Lock Valve LUBRICATING SYSTEM Lubricating System: A Lubricating System: B REPAIR KIT Repair Kit: A Repair Kit: B Repair Kits,: A Repair Kits,: B Repair Kits: A Repair Kits: B Repair Kits: C |
| Specification | |
| Descriptions | Included in repair kit for lock valve. Included in repair kit for operating cylinder. Replaced by 1pc 382913 cable and 1pc 267345 lever. |
