Oil cooler 8149982
| No. | Part Name | Part Number | Qty | Description |
| 1 | Oil cooler | 8149982 | 1 | |
| 2 | Plug | 479979 | 1 | |
| 3 | Plate | 1556594 | 1 | |
| 4 | Sealing ring | 8192187 | 4 | |
| 5 | Sealing ring | 8192189 | 1 | |
| 6 | Retainer | 471804 | 4 | |
| 7 | Flange screw | 984760 | 4 | |
| 8 | Connecting pipe, cylinder block | 1543868 | 1 | |
| 9 | Sealing ring | 1556905 | 2 | |
| 10 | Flange screw | 994386 | 2 | |
| 11 | Flange screw | 984736 | 2 | |
| 12 | Coolant pipe | 1556882 | 1 | (1543813) |
| 13 | Sealing ring | 1556905 | 1 | |
| 14 | Sealing ring | 1543572 | 2 | |
| 15 | Sealing ring | 1556949 | 1 | |
| 16 | Flange screw | 994387 | 1 | |
| 17 | Flange screw | 984736 | 1 | |
| 18 | Tube | 471634 | 1 | |
| 19 | Flange screw | 984736 | 2 | |
| 20 | Housing | 1543608 | 1 | |
| 21 | Sealing ring | 1543577 | 1 | |
| 22 | Compression spring | 1543615 | 1 | By-pass |
| 23 | Peg | 1543610 | 1 | |
| 24 | Seat | 1543964 | 1 |
| Item | Part Name | Part No. |
| 1 | Oil cooler 8149982 | 8149982 |
| Details | |
| Engine model | TAD1630P, TWD1630P, TWD1630PP, TAD1630PB TAD1630V, TWD1630V TD164KAE TID162AG, TID162AGP, TID162AP, TID162APB TWD1620G, TWD1630G, TAD1630G, TAD1630GE, TAD1631G, TAD1631GE |
| Application | Oil Cooler |
