Piston ring kit 875798
| No. | Part Name | Part Number | Qty | Description |
| 1 | Cylinder liner kit | 875837 | 6 | |
| 3 | Sealing ring kit | 875799 | 6 | |
| 8 | Piston ring kit | 875798 | 6 | |
| 12 | Gudgeon pin | 423342 | 6 | |
| 13 | Snap ring | 423124 | 12 | |
| 14 | Connecting rod | 846864 | 6 | |
| 15 | Bushing | 470434 | 6 | |
| 16 | Screw | 417464 | 12 | |
| 17 | Adjusting washer | 468271 | 1 | TH=0.20mm |
| 17 | Adjusting washer | 468272 | 1 | TH=0.30mm |
| 17 | Adjusting washer | 468273 | 1 | TH=0.50mm |
| 18 | Big-end bearing kit | 270130 | 6 | Std D |
| 18 | Big-end bearing kit | 270131 | 6 | 0,25mm u.s |
| 18 | Big-end bearing kit | 270132 | 6 | 0,50mm u.s |
| 21 | Crankshaft | 846444 | 1 | (837641) |
| 22 | Woodruff key | 422253 | 1 | |
| 24 | Main bearing kit | 270449 | 7 | Std |
| 24 | Main bearing kit | 270450 | 7 | 0.25mm u.s |
| 24 | Main bearing kit | 270451 | 7 | 0.50mm u.s |
| 25 | Thrust washer kit | 276791 | 1 | Std D |
| 25 | Thrust washer kit | 276792 | 1 | 0,1mm o.s |
| 25 | Thrust washer kit | 276793 | 1 | 0,2mm o.s |
| 26 | Gear | 423080 | 1 | |
| 27 | Oil deflector | 423177 | 1 | |
| 28 | Hub | 469489 | 1 | (422123) |
| 29 | Washer | 422124 | 1 | |
| 30 | Hexagon screw | 941494 | 1 | |
| 32 | V-belt pulley | 468187 | 1 | HC50x3 grooves |
| 32 | Pulley | 847367 | 1 | HC50x6 grooves |
| 33 | Hexagon screw | 955549 | 6 | AQ170B MOXXXX/87713-., L=45mm |
| 33 | Hexagon screw | 955551 | 12 | D70B spec. 867054, 867055, 867061, 867062, 867063, 867132, TD70B spec. 867065. |
| 34 | Spring washer | 941909 | 12 | AQ170B MOXXXX/87713-., BB170B MOXXXX/89353-. |
| 35 | Flywheel | 847168 | 1 | Std |
| 36 | Gear ring | 423082 | 1 | |
| 37 | Hexagon screw | 941570 | 10 | |
| 38 | Washer | 467773 | 10 |
| Item | Part Name | Part No. |
| 8 | Piston ring kit 875798 | 875798 |
| Details | |
| Engine model | TD120HPP TID120HPP |
| Application | CRANKSHAFT AND RELATED PARTS REPAIR KITS |
