Plug 466230
| No. | Part Name | Part Number | Qty | Description |
| 1 | Cylinder head | 4804587 | 1 | |
| 2 | Valve seat | 421011 | 4 | Std D |
| 2 | Valve seat | 421316 | 4 | 0.20mm o.s |
| 3 | Valve seat, exhaust | 4804548 | 4 | Std D |
| 4 | Valve guide | 466330 | 8 | |
| 5 | Sleeve | 466403 | 4 | |
| 6 | O-ring | 466922 | 4 | (944124) |
| 7 | Sealing ring | 466405 | 4 | |
| 8 | Ring | 466420 | 4 | |
| 9 | Expansion plug | 477026 | 3 | (192426) |
| 10 | Plug | 466230 | 3 | |
| 11 | Gasket | 420166 | 3 | |
| 12 | Plug | 785765 | 1 | |
| 13 | Gasket | 785766 | 1 | |
| 14 | Plug | 952358 | 1 | MO-21082/XXXXX |
| 15 | Plug | 467365 | 1 | |
| 16 | Gasket | 468461 | 1 | |
| 17 | Jet | 465420 | 4 | |
| 18 | Inlet valve | 466379 | 4 | |
| 19 | Exhaust valve | 842080 | 4 | (471195) |
| 20 | Valve spring | 466384 | 8 | |
| 21 | Valve spring | 466383 | 8 | |
| 22 | Valve spring washer | 466382 | 8 | |
| 23 | Valve cotter | 468305 | 16 | |
| 24 | Protecting ring | 469456 | 8 | Replaced by 1pc 829493, 1pc 833521, 1pc 957181., (466932) |
| 25 | Valve cap | 478074 | 8 | |
| 26 | Bearing bracket | 785558 | 4 | |
| 27 | Hexagon screw | 955539 | 4 | |
| 28 | Hexagon screw | 955540 | 4 | MOXXXXX/105195- |
| 29 | Spring washer | 942336 | 8 | |
| 30 | Rocker arm shaft | 785425 | 1 | |
| 31 | Cap plug | 955082 | 2 | |
| 32 | Rocker arm | 420129 | 4 | |
| 32 | Rocker arm | 420132 | 4 | |
| 33 | Bushing | 420125 | 8 | |
| 34 | Ball stud | 423058 | 8 | |
| 35 | Hexagon nut | 940175 | 8 | |
| 36 | Valve spring | 411140 | 2 | |
| 37 | Spring | 301466 | 3 | |
| 38 | Retaining ring | 914456 | 2 | |
| 39 | Valve cover | 785415 | 1 | |
| 40 | Gasket | 785416 | 1 | |
| 41 | Cross recessed screw | 950046 | 8 | |
| 42 | Oil filler cap | 421753 | 1 | |
| 43 | Gasket | 940096 | 1 | |
| 44 | Screw | 787459 | 16 | D42A PP SPEC. 16053, 867638. |
| 45 | Screw | 787458 | 4 | D42A PP SPEC. 16053, 867638. |
| 46 | Gasket kit | 6630496 | 1 | (6630283) |
| 46 | Gasket | 11030004 | 1 | Repl by 11990104 |
| 46 | Gasket kit | 11990017 | 1 | Repl by 11990104 |
| 46 | Gasket kit | 11990104 | 1 | |
| 47 | Sealing ring | 422413 | 1 | D=11mm |
| 49 | Hexagon screw | 940115 | 2 | |
| 46A | Gasket | 4804362 | 1 | D42A PP SPEC. 16053, 867638. |
| Item | Part Name | Part No. |
| 10 | Plug 466230 | 466230 |
| Details | |
| Engine model | D42A D70B D70CHC D70CRC TD45B TD60A TD60B TD60D TD60D-83 TD70B TD70CHC TD70CRC TD70G TD70G-83 TID60D TID60DG TID70G |
| Application | CYLINDER HEAD CYLINDER HEAD: A CYLINDER HEAD: B Cylinder Head: C Cylinder Head: D |
