Plug 952078
| No. | Part Name | Part Number | Qty | Description |
| 1 | Housing | 382975 | 1 | |
| 2 | Magnetic plug | 951906 | 2 | |
| 3 | Plug | 952078 | 1 | |
| 4 | Oil filter | 382353 | 1 | |
| 6 | Gasket | 382361 | 1 | |
| 7 | Hexagon screw | 940133 | 2 | |
| 8 | Spring washer | 942336 | 2 | |
| 9 | Plate | 382351 | 1 | |
| 10 | Hexagon screw | 940133 | 2 | |
| 11 | Spring washer | 941908 | 2 | |
| 12 | Inspection cover | 382009 | 1 | |
| 13 | Gasket | 382010 | 1 | |
| 14 | Hexagon screw | 940133 | 6 | |
| 15 | Spring washer | 941908 | 6 | |
| 22 | Hexagon nut | 943805 | 1 | |
| 25 | Hexagon screw | 955537 | 5 | |
| 26 | Spring washer | 941908 | 5 | |
| 29 | Cover | 382165 | 1 | |
| 31 | Hexagon screw | 955535 | 4 | |
| 32 | Spring washer | 941908 | 4 | |
| 33 | Gasket | 382161 | 1 | |
| 34 | Gasket | 382164 | 1 | |
| 35 | Shim | 941292 | 1 | TH=0.35mm |
| 35 | Shim | 941293 | 1 | TH=0.50mm |
| 36 | Sealing ring | 943703 | 1 | |
| 38 | Hexagon screw | 955535 | 7 | |
| 39 | Hexagon screw | 955541 | 2 | |
| 40 | Spring washer | 941908 | 9 | |
| 41 | Cover | 382245 | 1 | |
| 42 | Hexagon screw | 955590 | 6 | For charging of 2 batteries,use charge distributor 831793 |
| 43 | Disc spring | 382005 | 6 | |
| 44 | Cover | 382163 | 1 | |
| 45 | Hexagon screw | 940115 | 5 | |
| 46 | Spring washer | 941908 | 5 | |
| 49 | Hexagon screw | 955539 | 11 | |
| 49 | Hexagon screw | 955540 | 2 | MOXXXXX/105195- |
| 49 | Hexagon screw | 955542 | 4 | |
| 50 | Spring washer | 941908 | 17 | |
| 51 | Elbow nipple | 180283 | 1 | |
| 52 | Hose | 185504 | 1 | D=11,5mm, i.d=8mm |
| 56 | Cover plate | 382503 | 1 | |
| 57 | Gasket | 382504 | 1 | |
| 58 | Screw | 950009 | 2 | |
| 59 | Toothed washer | 955945 | 2 | AQ290A MO 20460-. |
| 21A | Dust cover | 382015 | 1 |
| Item | Part Name | Part No. |
| 3 | Plug 952078 | 952078 |
| Details | |
| Engine model | D70B TD70B TD70G |
| Application | Gear Box 254602, 254603: 254602 Gear Box 254602, 254603: 254603 Gear Box R60 254420 Gear Box R60 254420, 254424: 254420 Gear Box R60 254420, 254424: 254424 Rear Axle 16 ton FA N2 80 Rear Axle 8-12 ton RA N1 81 Rear Axle 8-12 ton RA N1 81: 1520481 Rear Axle 8-12 ton RA N1 81: 1520482 Rear Axle 8-12 ton RA N1 81: 1520524 Rear Axle 8-12 ton RA N1 81: 1520568 Thermostat and Water Pump with Installation Components Thermostat and Water Pump with Installation Components: A Thermostat and Water Pump with Installation Components: B |
| Specification | |
| Descriptions | Alt MO-109500/XXXXX |
