Protecting plate 865261
| No. | Part Name | Part Number | Qty | Description |
| 1 | Bearing housing | 420903 | 1 | |
| 2 | Sealing ring | 424580 | 1 | (941580) |
| 3 | Axle shaft | 471557 | 1 | |
| 4 | Ball bearing | 11013 | 1 | |
| 5 | Gear | 469364 | 1 | |
| 6 | Stop ring | 469363 | 1 | |
| 7 | Ball bearing | 181577 | 1 | |
| 8 | Washer | 423074 | 1 | |
| 9 | Hexagon screw | 955274 | 6 | |
| 10 | Washer | 955892 | 6 | |
| 11 | Pin | 950586 | 1 | |
| 12 | Screw | 471558 | 3 | |
| 13 | Gear | 478297 | 1 | |
| 14 | Sealing ring | 423123 | 1 | |
| 15 | Hexagon screw | 940159 | 5 | |
| 16 | Spring washer | 941907 | 5 | |
| 17 | Companion flange | 471383 | 1 | |
| 18 | Spacer | 471367 | 1 | |
| 19 | Companion flange | 471312 | 1 | |
| 20 | Flexplate | 479459 | 6 | |
| 21 | Flange screw | 946470 | 8 | |
| 22 | Flange nut | 945408 | 8 | |
| 23 | Washer | 976944 | 8 | |
| 24 | Washer | 479460 | 8 | |
| 25 | Guide sleeve | 478896 | 8 | |
| 26 | Hexagon screw | 970878 | 1 | |
| 27 | Washer | 976945 | 1 | |
| 28 | Protecting plate | 865261 | 1 | |
| 29 | Hexagon screw | 955527 | 1 | |
| 30 | Washer | 976944 | 1 | |
| 31 | Spacer sleeve | 807425 | 1 | L=24mm |
| Item | Part Name | Part No. |
| 28 | Protecting plate 865261 | 865261 |
| Details | |
| Engine model | TD100G-87 TD1010G, TWD1010G TD1030VE |
| Application | Coupling for Fuel Injection Pump with Cover Coupling for Fuel Injection Pump with Cover, Later Production |
