Protecting ring 469456
| No. | Part Name | Part Number | Qty | Description |
| 0 | Gasket | 11994 | 2 | |
| 0 | Gasket | 11996 | 1 | |
| 0 | Gasket | 11998 | 1 | |
| 0 | Gasket | 18671 | 1 | |
| 0 | Gasket, plug | 18677 | 3 | |
| 0 | Gasket | 18818 | 1 | |
| 0 | Gasket | 18822 | 1 | |
| 0 | Gasket | 239896 | 1 | |
| 0 | Tappet | 239982 | 6 | |
| 0 | Sealing washer | 239993 | 1 | |
| 0 | O-ring | 240001 | 6 | |
| 0 | Sealing ring | 240022 | 1 | |
| 0 | Roller bearing | 240023 | 1 | |
| 0 | O-ring | 240422 | 12 | |
| 0 | Bearing | 240426 | 1 | |
| 0 | Control sleeve | 240782 | 6 | |
| 0 | Camshaft | 240789 | 1 | |
| 0 | Control rod | 240907 | 1 | |
| 0 | Gasket | 240948 | 1 | |
| 0 | Compression spring | 240969 | 6 | |
| 0 | O-ring | 243299 | 1 | |
| 0 | Pump element | 244470 | 6 | |
| 0 | Delivery valve | 244471 | 6 | |
| 0 | Compression spring | 244731 | 6 | (847277) |
| 0 | Repair kit | 272665 | 1 | |
| 0 | Repair kit | 273714 | 1 | See group 10A |
| 0 | Repair kit | 276543 | 1 | |
| 0 | Spring | 324355 | 1 | |
| 0 | Ring | 326834 | 2 | |
| 0 | O-ring | 326835 | 2 | |
| 0 | Guide | 326839 | 1 | |
| 0 | Piston | 331876 | 2 | |
| 0 | Push rod | 331877 | 2 | |
| 0 | Guide | 331878 | 2 | |
| 0 | Bearing | 344231 | 1 | |
| 0 | Gasket | 411545 | 2 | |
| 0 | Gasket | 413619 | 1 | |
| 0 | Sealing ring | 416033 | 2 | |
| 0 | Gasket | 421066 | 2 | |
| 0 | Valve cap | 469365 | 12 | (417133) |
| 0 | Protecting ring | 469456 | 12 | Replaced by 1pc 829493, 1pc 833521, 1pc 957181., (466932) |
| 0 | Sealing ring | 469846 | 4 | |
| 0 | Repair kit | 845240 | 1 | See group 10A |
| 0 | Gasket kit, gasket kit reconditioning | 875679 | 1 | |
| 0 | De-carbonizing kit, gasket kit decarbonizing. | 875680 | 1 | |
| 0 | O-ring | 949656 | 3 | |
| 0 | O-ring | 964114 | 1 | |
| 0 | Gasket | 1518373 | 1 | |
| 0 | Gasket | 1518375 | 1 | |
| 0 | Gasket | 1695152 | 1 | (1518352) |
| Item | Part Name | Part No. |
| 0 | Protecting ring 469456 | 469456 |
| Details | |
| Engine model | D100A D100A, TD100A D100B D100BHC D100BRC D120A D70B D70CHC D70CRC TAD120AHC TAD730G TAD730P TAD730V TD100A TD100AHC TD100ARC TD120AHC TD120ARC TD45B TD70B TD70CHC TD70CRC TD70G TD70G-83 TD710G TD710G, TWD710G TD71A TD730ME TD730VE TID70G TID71A TWD710G TWD710P TWD710V TWD730ME, TWD731ME TWD731VE |
| Application | Cylinder Head Cylinder Head: A Cylinder Head: B Cylinder Head: C Cylinder Head: D Repair Kit Repair Kit: A Repair Kit: B Repair Kits: A Repair Kits: B Repair Kits: C REPAIR KITS: D |
| Specification | |
| Descriptions | (407224) (466932) Replaced by 1pc 829493, 1pc 833521, 1pc 957181., (466932) SN-2071104427 |
