Pulley 4772117
| No. | Part Name | Part Number | Qty | Description |
| 1 | Cylinder liner kit | 3827380 | 6 | SN2071097293- |
| 3 | Sealing ring kit | 271159 | 6 | |
| 4 | Piston ring kit | 876542 | 6 | |
| 6 | Gudgeon pin | 3978588 | 6 | Std D |
| 7 | Snap ring | 914525 | 12 | |
| 8 | Shim | 3978758 | 1 | TH=0.12mm |
| 8 | Shim | 3978759 | 1 | TH=0.20mm |
| 8 | Shim | 3978760 | 1 | TH=0.30mm |
| 8 | Shim | 3978761 | 1 | TH=0.50mm |
| 9 | Connecting rod | 864936 | 6 | (471523) |
| 10 | Flange screw | 465815 | 12 | |
| 11 | Bushing | 471364 | 6 | (466454) |
| 12 | Crankshaft | 24424609 | 1 | SN2071097293-, Included woodruff key 422253, pin 950677 and gear 471528. |
| 13 | Woodruff key | 422253 | 1 | |
| 14 | Gear, crankshaft | 471528 | 1 | |
| 15 | Hub | 465779 | 1 | |
| 16 | Washer | 420124 | 1 | |
| 17 | Flange screw | 470366 | 1 | |
| 18 | Vibration damper | 888019 | 1 | For twin alternators. |
| 18 | Oscillation damper | 3825339 | 1 | (421515) |
| 19 | Pulley | 4772117 | 1 | 3-groove |
| 20 | Flange screw | 471529 | 8 | |
| 21 | Big-end bearing kit | 270115 | 6 | Std D |
| 21 | Big-end bearing kit | 270116 | 6 | 0,25mm u.s |
| 21 | Big-end bearing kit | 270117 | 6 | 0,50mm u.s |
| 21 | Big-end bearing kit | 270118 | 6 | 0,75mm u.s |
| 21 | Big-end bearing kit | 270119 | 6 | 1,00mm u.s |
| 21 | Big-end bearing kit | 270120 | 6 | 1,25mm u.s |
| 22 | Main bearing kit | 276894 | 7 | SN2071097293-, Std |
| 22 | Main bearing kit | 276895 | 7 | SN2071097293-, U.S=0,25mm |
| 22 | Main bearing kit | 276896 | 7 | SN2071097293-, U.S=0,50mm |
| 22 | Main bearing kit | 276897 | 7 | SN2071097293-, U.S=0,76mm |
| 22 | Main bearing kit | 276898 | 7 | SN2071097293-, U.S=1,01mm |
| 22 | Main bearing kit | 276899 | 7 | SN2071097293-, U.S=1,27mm |
| 23 | Thrust washer kit | 276890 | 1 | SN2071097293-, Std |
| 23 | Thrust washer kit | 276891 | 1 | SN2071097293-, O.S=0,10mm |
| 23 | Thrust washer kit | 276892 | 1 | SN2071097293-, O.S=0,20mm |
| 23 | Thrust washer kit | 276893 | 1 | SN2071097293-, O.S=0,30mm |
| 12A | Pin | 950677 | 1 |
| Item | Part Name | Part No. |
| 19 | Pulley 4772117 | 4772117 |
| Details | |
| Engine model | TAD730G TAD730P TAD730V TAD741GE TD610G, TWD610G TD610M TD610V, TWD610V TD61A, TD61AW TD630ME, TWD630ME TD630VE, TWD630VE TD640VE TD710G TD71A, TD71AW, TID71A TD71A, TID71A, TWD710V TD71AG, TID71AG TD730ME, TWD730ME, TWD731ME TD730VE, TWD731VE TWD610P TWD710G TWD710P TWD730ME TWD740GE, TAD740GE TWD740VE |
| Application | Crank Mechanism Crank Mechanism SN-2071097292: A Crank Mechanism SN-2071097292: B Crank Mechanism SN-2071097292: C Crank Mechanism SN2071097293-: A Crank Mechanism SN2071097293-: B Crank Mechanism SN2071097293-: C Crank Mechanism, SN-2061106089 Crank Mechanism, SN-2061106089: A Crank Mechanism, SN-2061106089: B Crank Mechanism, SN-2071078953 Crank Mechanism, SN2061106090- Crank Mechanism, SN2061106090-: A Crank Mechanism, SN2061106090-: B Crank Mechanism, SN2071078954- Crank Mechanism: A Crank Mechanism: B Crank Mechanism: C Crankshaft and Related Parts |
| Specification | |
| Descriptions | 3 groove 3 spår-3 groove 3-groove |
