Radiator 848880
| No. | Part Name | Part Number | Qty | Description |
| 1 | Radiator | 848880 | 1 | |
| 2 | Rubber cushion | 849170 | 2 | |
| 3 | Sleeve | 807228 | 2 | |
| 4 | Hexagon nut | 955850 | 4 | |
| 5 | Spring washer | 940280 | 4 | |
| 6 | Radiator stay | 848830 | 1 | |
| 7 | Washer | 191940 | 4 | |
| 8 | Spacer sleeve | 252202 | 2 | |
| 9 | Rubber washer | 252203 | 4 | |
| 10 | Spring washer | 941912 | 2 | |
| 11 | Hexagon nut | 955793 | 3 | |
| 12 | Hose | 848826 | 1 | Radiator-thermostat housing. |
| 13 | Radiator hose | 848827 | 1 | Radiator-water pump. |
| 14 | Hose clamp | 943480 | 4 | MO-XXXXX/98707., (951797) |
| 15 | Pressure cap | 350578 | 1 | (321973) |
| 16 | Rubber hose | 944386 | 1 | |
| 17 | Elbow nipple | 942649 | 1 | |
| 18 | Hose clamp | 994560 | 2 | |
| 19 | Gasket | 11994 | 1 | |
| 20 | Plug | 947660 | 1 | (836268) |
| 21 | Fan protector | 848874 | 1 | Repl by 2pcs 862966 |
| 22 | Spacer sleeve | 847310 | 4 | L=78mm for 848874 |
| 23 | Flange screw | 965184 | 4 | |
| 24 | Fan shroud | 848887 | 1 | D=770mm |
| 25 | Flange screw | 946025 | 10 | |
| 26 | Fan, suction type | 843868 | 1 | D=750mm |
| 26 | Fan, pusher type | 843869 | 1 | D=750mm |
| 27 | Flange screw | 946472 | 6 | |
| 28 | Flange screw | 965185 | 4 | |
| 29 | Fan hub | 849515 | 1 | |
| 31 | Hose clamp | 994556 | 1 |
| Item | Part Name | Part No. |
| 1 | Radiator 848880 | 848880 |
| Details | |
| Engine model | TD120HP-86, TD121GP-87, TID121KP, TID121KP-87, TID121LP, TID121LP-87 TD121GG-86, TD121GG-87 |
| Application | Radiator and Fan with Installation Components Radiator and Fan with Installation Components, Power Pack |
