Rain cap 845580
| No. | Part Name | Part Number | Qty | Description |
| 2 | Inlet manifold | 423271 | 1 | |
| 2 | Inlet manifold | 468551 | 1 | Early production D70B spec. 867060. TD70B spec. 867066. |
| 3 | Rubber ring | 423174 | 6 | |
| 4 | Hexagon screw | 940113 | 1 | |
| 5 | Gasket | 957171 | 1 | |
| 6 | Plug | 180707 | 2 | |
| 7 | Gasket | 957173 | 2 | |
| 9 | Hexagon screw | 955532 | 4 | Only for thermoswitch control 837500,837501., L=95mm |
| 9 | Hexagon screw | 955533 | 4 | For engine with 40° angle of inclination, L=102mm |
| 10 | Hexagon screw | 955530 | 4 | |
| 11 | Hexagon screw | 940136 | 2 | |
| 12 | Hexagon screw | 940161 | 2 | For engine with 40° angle of inclination, L=45mm |
| 13 | Spring washer | 941907 | 12 | |
| 14 | Sealing ring | 423057 | 4 | |
| 15 | Connecting pipe | 423320 | 1 | |
| 15 | Connecting pipe | 468257 | 1 | See group 3 |
| 16 | Gasket, flange | 423336 | 1 | |
| 16 | Gasket | 468243 | 1 | When coolant supervision not is mounted |
| 17 | Hexagon screw | 940159 | 4 | |
| 18 | Washer | 955894 | 4 | |
| 19 | Spring washer | 941907 | 4 | |
| 20 | Exhaust pipe | 423274 | 2 | |
| 21 | Exhaust pipe | 836266 | 1 | |
| 22 | Gasket | 468647 | 6 | |
| 23 | Hexagon screw | 955536 | 12 | AQ115A MOXXXX/86909-., Repl by 1pc 840539 bracket (8 holes), 9PCS 941907 6PCS 9552 97, 2pcs 955298., Late type |
| 24 | Spacer sleeve | 422217 | 12 | |
| 25 | Washer | 941744 | 12 | |
| 26 | Lock washer | 423350 | 6 | |
| 27 | Plug | 16318 | 1 | |
| 28 | Gasket | 907132 | 1 | |
| 35 | Nut | 943152 | 4 | |
| 36 | Stud | 953259 | 4 | |
| 37 | Gasket | 417382 | 1 | |
| 40 | Exhaust hose, exhaust hose | 846308 | 1 | (821278) |
| 41 | Flange | 330287 | 1 | TD60B spec. 867618, 867648., Used when expansion tank 351579 is mounted, Replaced by 1pc 843088 and 8PCS 955365. |
| 41 | Flange | 844476 | 1 | Late type |
| 42 | Gasket | 411710 | 1 | |
| 43 | Stud | 953259 | 6 | |
| 44 | Nut | 943152 | 6 | |
| 45 | Washer | 960148 | 6 | Spec. 867446, 867477, 867494, 867630, 867618., MAFI spec. 867578. |
| 46 | Tab washer | 15193 | 3 | |
| 47 | Gasket | 807578 | 1 | |
| 48 | Flange | 807625 | 1 | |
| 49 | Radiation shield | 822987 | 1 | |
| 50 | Hose clamp | 943479 | 1 | |
| 51 | Hose clamp | 943482 | 1 | (951798) |
| 52 | Exhaust pipe | 423274 | 2 | |
| 53 | Exhaust pipe | 836266 | 1 | |
| 54 | Brace | 842448 | 4 | Åkerman spec. 867454., Engine with oil cooler fitted on front of the engine. |
| 55 | Sealing cord | 843445 | 1 | Ers av 1 pc 466833,1st 465473., Replaced by 1pc 843088 and 8PCS 955365. |
| 56 | Brace | 836265 | 4 | |
| 57 | Hexagon screw | 955518 | 8 | Ers av 1 pc 466833,1st 465473., Replaced by 1pc 843088 and 8PCS 955365. |
| 58 | Lock nut | 944579 | 8 | Ers av 1 pc 466833,1st 465473., Replaced by 1pc 843088 and 8PCS 955365. |
| 62 | Exhaust pipe | 844478 | 1 | Spec. 867277, MOXXXXX/32502-., Early type |
| 62 | Rain cap | 845580 | 1 | Late type alt 4'' |
| 63 | Protecting cover | 844520 | 1 | Early type |
| 64 | Shaft | 844522 | 1 | Early type |
| 65 | Washer | 955892 | 2 | |
| 66 | Split pin | 907824 | 2 |
| Item | Part Name | Part No. |
| 62 | Rain cap 845580 | 845580 |
| Details | |
| Engine model | D100A D100B TD100A TD120A TD120GG |
| Application | Exhaust Bend and Installation Components Induction- and Exhaust Manifold: A Induction- and Exhaust Manifold: B Induction- and Exhaust Manifold: C INDUCTION-AND EXHAUST MANIFOLD: B |
| Specification | |
| Descriptions | Late type 4'' Late type alt 4'' |
