Rubber fitting 837178
| No. | Part Name | Part Number | Qty | Description |
| 1 | Air filter | 823701 | 2 | Late type |
| 2 | Tensioning band | 821028 | 4 | |
| 3 | Clevis pin, threaded | 31404 | 4 | |
| 4 | Pin | 31405 | 4 | |
| 5 | Hexagon screw | 31406 | 4 | |
| 6 | Rubber hose | 824470 | 2 | Early type |
| 7 | Rubber fitting | 836334 | 2 | For 804961., D=105mm-113mm |
| 8 | Hose clamp | 943484 | 4 | (951801) |
| 9 | Pressure drop indica | 822984 | 1 | MO-XXXXX/18921 |
| 9 | Pressure drop indica | 842037 | 1 | |
| 10 | Nipple | 191095 | 1 | |
| 11 | Nipple | 823953 | 1 | When oil supervision not is mounted. |
| 12 | Plug | 192114 | 1 | |
| 13 | Gasket | 957185 | 1 | |
| 14 | Plug | 952077 | 1 | |
| 23 | Bracket | 823808 | 2 | |
| 24 | Spacer sleeve | 807250 | 2 | L=16mm (826652) |
| 24 | Spacer sleeve | 820917 | 1 | Replaced by 2pcs 845838, 1pc 955129. |
| 25 | Spacer sleeve | 807184 | 2 | L=6mm |
| 26 | Hexagon screw | 955533 | 4 | For engine with 40° angle of inclination, L=102mm |
| 27 | Hexagon screw | 955530 | 1 | |
| 27 | Hexagon screw | 955531 | 1 | Late type |
| 28 | Spring washer | 941907 | 5 | |
| 30 | Hose | 13516 | 1 | L=100mm |
| 31 | Hose clamp | 943483 | 2 | (951800) |
| 32 | Connecting pipe | 842523 | 1 | Late type |
| 33 | Rubber fitting | 837178 | 1 | Late type |
| 34 | Hose clamp | 943483 | 1 | (951800) |
| 35 | Hose clamp | 961907 | 1 | Late type |
| 36 | Stay | 823952 | 1 | |
| 37 | Hexagon screw | 955523 | 1 | |
| 38 | Washer | 955894 | 1 | |
| 39 | Spring washer | 941907 | 1 |
| Item | Part Name | Part No. |
| 33 | Rubber fitting 837178 | 837178 |
| Details | |
| Engine model | TD120A TD120C TD120G, TD120GG TD120HPP TD121G-87 |
| Application | Air Filter and Installation Components Air Filter and Installation Components: B Air Filter, Side Installation Turbo and Installation Components, Classed Engine |
| Specification | |
| Descriptions | Late type |
