Screw 244493
| No. | Part Name | Part Number | Qty | Description |
| 1 | Feed pump | 244391 | 1 | Repl by 1699140 |
| 3 | O-ring | 240270 | 1 | |
| 4 | Pump piston | 240548 | 1 | D=21,989-21,994mm |
| 5 | Push rod | 243374 | 1 | D=4,993-4,998mm |
| 6 | Spring | 244392 | 1 | |
| 7 | Screw | 244493 | 1 | |
| 8 | Gasket | 18844 | 1 | |
| 9 | Tappet | 244393 | 1 | |
| 13 | Spring ring | 238368 | 1 | |
| 14 | Valve | 243136 | 2 | |
| 15 | Compression spring | 76706 | 2 | |
| 16 | Plug | 25278 | 1 | |
| 17 | Gasket | 240572 | 2 | |
| 18 | Hand pump | 3826073 | 1 |
| Item | Part Name | Part No. |
| 7 | Screw 244493 | 244493 |
| Details | |
| Application | Fuel Feed Pump Fuel Feed Pump, Components Fuel Feed Pump: 244391 |
