Sealing ring 1545271
| No. | Part Name | Part Number | Qty | Description |
| 1 | Oil pump | 479319 | 1 | |
| 1 | Oil pump | 1545119 | 1 | |
| 2 | Tab washer | 190529 | 2 | |
| 2 | Spring washer | 942336 | 4 | |
| 3 | Hexagon screw | 955538 | 4 | |
| 4 | Suction pipe | 824156 | 1 | |
| 5 | O-ring | 949658 | 1 | (925061) early type |
| 6 | Hexagon screw | 955530 | 2 | |
| 7 | Spring washer | 941907 | 2 | |
| 8 | Oil pressure pipe | 1545270 | 1 | Late type |
| 9 | Flange | 1545272 | 1 | Late type |
| 10 | Sealing ring | 1545271 | 1 | Late type |
| 11 | Hexagon screw | 955531 | 2 | Late type |
| 12 | Spring washer | 941907 | 2 | |
| 13 | Fitting | 466907 | 1 | |
| 14 | Baffle plate | 1545381 | 1 | |
| 15 | Bracket | 1545011 | 1 | Late type |
| 16 | Flange screw | 942402 | 2 | |
| 17 | Bracket | 1545203 | 1 | Late type |
| 18 | Attaching clamp | 1545433 | 1 | |
| 19 | Hexagon screw | 940117 | 3 | Late type |
| 20 | Spacer sleeve | 1545269 | 3 | Late type |
| 21 | Hexagon nut | 955825 | 3 | Late type |
| 22 | Washer | 960140 | 3 | 3-6mm², yellow |
| 23 | Flange screw | 942402 | 2 | |
| 24 | Spring washer | 941907 | 2 | |
| 25 | Hexagon screw | 940113 | 2 | |
| 26 | Spring washer | 941907 | 2 | |
| 27 | Sump | 862014 | 1 | |
| 28 | Gasket | 479264 | 1 | |
| 29 | Flange screw | 942402 | 39 | |
| 30 | Magnetic plug | 949175 | 1 | |
| 31 | Gasket | 18813 | 1 | |
| 32 | Bracket, oil cooler | 467916 | 1 | |
| 33 | Hexagon screw | 955525 | 2 | |
| 34 | Spring washer | 941907 | 2 | |
| 35 | Oil dipstick | 862020 | 1 | |
| 36 | O-ring, bearing housing | 925054 | 1 | |
| 37 | Pipe retainer | 862016 | 1 | |
| 38 | Rubber washer | 468947 | 1 | |
| 39 | Hexagon nut | 468948 | 1 | |
| 40 | Oil dipstick | 848344 | 1 | |
| 41 | Extension pipe | 412845 | 1 | |
| 42 | Cover | 471752 | 1 | |
| 43 | Hexagon screw | 940100 | 2 | |
| 44 | Spring washer | 941906 | 2 | |
| 45 | O-ring | 949658 | 1 | (925061) early type |
| 46 | Reduction valve | 471706 | 1 | Marked blue |
| 47 | Sealing ring | 469846 | 1 |
| Item | Part Name | Part No. |
| 10 | Sealing ring 1545271 | 1545271 |
| Details | |
| Engine model | D100A D100B TD100A TD100ARC TD100CHC TD100CRC TD100G TD100G-85 TD100G-87 TD100GG TD100GG-85 TD100GG-87 TD100GP TD100GP-85 TD100HP-87 TD100HPB-87 TD1010G, TWD1010G TID100K TID100K-87 TID100KG TID100KG-87 TID100KGP-87 TID100KP TID100KP-87 TID100KPB-87 |
| Application | LUBRICATING SYSTEM Lubricating System Standard Model: A Lubricating System Standard Model: B Lubricating System Standard Model: C Lubricating System, Classed Engine: A Lubricating System, Standard: A Lubricating System, Standard: B Lubricating System, Standard: C Lubricating System, Standard: TD100GGP-87 Lubricating System: A Lubricating System: B Repair Kits Repair Kits: A Repair Kits: B Repair Kits: TD100-87 Repair Kits: TID100-87 |
| Specification | |
| Descriptions | Late type |
