Sealing ring 477118
| No. | Part Name | Part Number | Qty | Description |
| 1 | Timing gear casing | 471505 | 1 | |
| 2 | Pin | 941511 | 1 | For Aquamatic drive unit and Duoprop drive unit. |
| 3 | Pin | 941510 | 1 | For Aquamatic drive unit and Duoprop drive unit. |
| 4 | Sealant | 1161231 | 1 | 304ml |
| 5 | Flange screw | 471534 | 2 | |
| 5 | Flange screw | 471535 | 2 | L=58mm |
| 6 | Gear, crankshaft | 471528 | 1 | |
| 7 | Bearing spindle | 422766 | 1 | (467463) |
| 8 | Gear | 8192518 | 1 | (471552) |
| 9 | Thrust washer | 467529 | 1 | MO-608/XXXX. |
| 10 | Flange screw | 471554 | 3 | |
| 12 | Gear | 423087 | 1 | |
| 12 | Gear | 478289 | 1 | |
| 13 | Gear, gear fuel injection pump | 470764 | 1 | |
| 14 | Gear, oil pump | 471941 | 1 | |
| 15 | Idler gear, oil pump | 471942 | 1 | |
| 16 | Cover | 8192590 | 1 | (8192052) (471562) |
| 18 | Sealing ring | 477118 | 1 | (471055) |
| 20 | Sealant | 1161231 | 1 | 304ml |
| 21 | Flange screw | 947760 | 6 | M8x40mm |
| 21 | Flange screw | 948217 | 2 | |
| 21 | Flange screw | 965182 | 6 | |
| 21 | Flange screw | 965183 | 1 | |
| 21 | Flange screw | 965216 | 2 | |
| 22 | Cover | 465735 | 1 | (465057) |
| 23 | O-ring | 925094 | 1 | Included in gasket kit 876025 for induction manifold+intercooler. |
| 24 | Flange screw | 965222 | 1 | L=65mm |
| 25 | Stud | 924077 | 1 | |
| 26 | Washer | 955895 | 2 | |
| 27 | Flange nut | 971095 | 1 | Alt |
| 28 | Cover | 471559 | 1 | |
| 29 | O-ring | 925257 | 1 | |
| 30 | Flange screw | 945444 | 3 | |
| 31 | Spring washer | 941907 | 3 | |
| 32 | Stud | 967951 | 3 | |
| 33 | Flange nut | 971097 | 3 | |
| 34 | Oil filler pipe | 849197 | 1 | |
| 35 | Cover | 420178 | 1 | |
| 36 | Oil filler cap | 421753 | 1 | |
| 37 | Gasket | 940096 | 1 | |
| 38 | O-ring | 975610 | 1 | For engines without air compressor. |
| 39 | Plug | 960632 | 1 | |
| 40 | Gasket | 947624 | 1 |
| Item | Part Name | Part No. |
| 18 | Sealing ring 477118 | 477118 |
| Details | |
| Engine model | TAD730G TAD730P TAD730V TAD740GE TAD741GE TD610G TD610G, TWD610G TD610M, TD630ME TD610V TD610V, TWD610V, TD630VE TD630VE TD640VE TD710G, TWD710G, TAD730G TD71A TD71A, TID71A, TWD710V TD730ME TD730ME, TWD730ME, TWD731ME TD730VE TD730VE, TWD731VE TID71A TWD610G TWD610P TWD610V TWD630ME TWD630VE TWD710P TWD710P, TAD730P TWD710V TWD730ME TWD730ME, TWD731ME TWD731VE TWD740GE TWD740GE, TAD740GE, TAD741GE TWD740VE |
| Application | Repair Kits Repair Kits: A Repair Kits: B Repair Kits: C Timing Gear Casing and Gears Timing Gear Casing and Gears, SN-2071082971 Timing Gear Casing and Gears, SN2071082972- Timing Gear Casing and Gears: A Timing Gear Casing and Gears: B Timing Gear Casing and Gears: C |
| Specification | |
| Descriptions | (471055) |
Related Products
Tags: Sealing ring, Volvo Penta, 477118
