Sealing strip 837488
| No. | Part Name | Part Number | Qty | Description |
| 1 | Clutch housing | 837377 | 1 | |
| 2 | Cap | 837378 | 1 | |
| 3 | Cap | 837379 | 1 | |
| 4 | Clamping sleeve | 847742 | 2 | (837485) |
| 5 | Guide rail | 837483 | 1 | |
| 6 | Guide rail | 837484 | 1 | |
| 7 | Housing | 837486 | 4 | |
| 8 | Sealing strip | 837488 | 1 | |
| 9 | Grommet | 822327 | 1 | |
| 11 | Guard plate | 837558 | 1 | |
| 12 | Hose | 192618 | 1 | L=1400mm |
| 13 | Stud | 946945 | 1 | |
| 14 | Hexagon nut | 955825 | 2 | Late type |
| 15 | Hexagon screw | 955513 | 1 | |
| 16 | Hexagon screw | 940117 | 3 | Late type |
| 17 | Spring washer | 941906 | 7 |
| Item | Part Name | Part No. |
| 8 | Sealing strip 837488 | 837488 |
| Details | |
| Engine model | D100B, TD100A D120A, TD120A D70B D70CHC, D70CRC, TD70CHC, TD70CRC TAD120CHC TAD121CHC TD100ARC TD100CHC TD100CRC TD120AHC, TD120ARC, TAD120AHC, TAD120BHC TD120BHC TD120BRC TD121CHC TD121CRC |
| Application | Electrical System, Classed Engine Electrical System, Classed Engine Spec 867108, 867153 Electrical System, Classed Engine Spec.86717 Alt STARTER CASING AND INSTALLATION COMPONENTS Starter Casing and Installation Components: A Starter Casing and Installation Components: B |
