Selector valve, bracket with shifting valve 824199
Selector valve, bracket with shifting valve 824199
- Brandsvolvo penta
- Part No.: 824199
- Availability: 联系我们
| No. | Part Name | Part Number | Qty | Description |
| 1 | Bracket | 824187 | 1 | |
| 1 | Selector valve, bracket with shifting valve | 824199 | 1 | See group 2B |
| 2 | Valve peg | 824198 | 1 | |
| 3 | O-ring | 925057 | 2 | |
| 4 | Split pin | 907861 | 1 | |
| 5 | Flange | 824195 | 1 | |
| 6 | Cross recessed screw | 950022 | 2 | EXCL. SPEC. 9882, 9961, 9982 |
| 7 | Plug | 914392 | 3 | |
| 8 | Gasket | 907135 | 3 | |
| 8 | Gasket | 957184 | 4 | AQ115A MOXXXX/86909-. |
| 9 | Plug | 914391 | 2 | EXCL. SPEC. 9882, 9961, 9982. |
| 10 | Gasket | 18706 | 2 | EXCL. SPEC. 9882, 9961, 9982. |
| 11 | Hex. socket screw | 956571 | 3 | SEE GROUP 2B |
| 12 | Hex. socket screw | 956572 | 1 | SEE GROUP 2B |
| 13 | Gasket | 11992 | 4 | |
| 14 | O-ring | 960168 | 1 | |
| 15 | Rubber hose | 824193 | 1 | |
| 16 | Hollow screw | 944213 | 2 | |
| 17 | Gasket | 957189 | 2 | |
| 18 | Gasket | 957189 | 2 | |
| 19 | O-ring | 925060 | 2 | |
| 20 | Hexagon screw | 940162 | 3 | MO-XXXXX/105194 |
| 21 | Spring washer | 942336 | 3 | |
| 23 | Nipple | 423067 | 2 | |
| 24 | Oil filter | 4785974 | 2 |
| Item | Part Name | Part No. |
| 1 | Selector valve, bracket with shifting valve 824199 | 824199 |
| Details | |
| Engine model | TAD120AHC TD120AHC TD120AHC, TAD120AHC |
| Application | Oil Cooler with Installation Components Oil Filter with Installation Components |
| Specification | |
| Descriptions | See group 2A See group 2B |
Tags: Selector valve, bracket with shifting valve, Volvo Penta, 824199
