Shaft 241783
| No. | Part Name | Part Number | Qty | Description |
| 1 | Smoke limiter | 241738 | 1 | |
| 3 | Gasket | 241797 | 1 | |
| 4 | Hexagon screw | 955294 | 1 | |
| 5 | Washer | 241794 | 1 | |
| 6 | Hexagon screw | 955273 | 1 | |
| 7 | Screw | 241796 | 1 | |
| 8 | Spring washer | 941906 | 2 | |
| 9 | Indicator | 241648 | 1 | |
| 10 | Washer | 241795 | 2 | |
| 11 | Screw | 241781 | 1 | |
| 12 | Hexagon nut | 955781 | 1 | |
| 13 | Spring washer | 240769 | 1 | |
| 14 | Lever | 241782 | 1 | |
| 15 | Leaf spring | 243260 | 1 | |
| 16 | Screw | 243259 | 1 | (241785) |
| 17 | Hexagon nut | 955781 | 1 | |
| 18 | Spring washer | 240769 | 1 | |
| 19 | Shaft | 241783 | 1 | |
| 20 | Lock washer | 241784 | 1 | |
| 21 | Washer | 233816 | 1 | |
| 22 | Shaft | 241783 | 1 | |
| 23 | Brace | 241780 | 1 | |
| 24 | Stud | 241771 | 1 | |
| 25 | Lock spring | 241772 | 1 | |
| 27 | Spring | 241773 | 1 | |
| 28 | Spring disc | 241774 | 1 | |
| 29 | Diaphragm | 241775 | 1 | |
| 30 | Washer | 241776 | 1 | |
| 31 | Spring washer | 240769 | 1 | |
| 32 | Hexagon nut | 955781 | 1 | |
| 33 | Pin | 241788 | 1 | |
| 34 | E-circlip | 951667 | 1 | |
| 35 | Cover | 243270 | 1 | |
| 36 | Screw | 241778 | 2 | |
| 37 | Screw | 241779 | 2 | |
| 39 | Gasket | 241790 | 2 | |
| 41 | Cross recessed screw | 956092 | 5 | (241793) |
| 42 | Screw | 239318 | 2 | |
| 44 | Hexagon nut | 955781 | 1 | |
| 45 | Rubber bellows | 241792 | 1 |
| Item | Part Name | Part No. |
| 19 | Shaft 241783 | 241783 |
| Details | |
| Engine model | TWD1030ME |
| Application | Smoke Eleminator Smoke Eliminator Smoke Limiter |
