Slide bearing 477160
| No. | Part Name | Part Number | Qty | Description |
| 1 | Belt tensioner | 421540 | 1 | |
| 2 | Cable | 477312 | 1 | |
| 3 | Compression spring | 471318 | 1 | |
| 4 | Spring guide | 471323 | 2 | |
| 5 | Ring | 1134962 | 2 | |
| 6 | Spring anchorage | 471325 | 1 | |
| 7 | Washer | 955892 | 1 | |
| 8 | Nut | 421541 | 1 | |
| 9 | Washer | 960140 | 1 | 3-6mm², yellow |
| 10 | Hexagon nut | 955781 | 1 | |
| 12 | Arm | 471313 | 1 | |
| 13 | Pulley | 1661878 | 1 | |
| 14 | Ball bearing | 1544092 | 1 | (181430) |
| 15 | Washer | 947354 | 1 | |
| 16 | Flange screw | 949894 | 1 | |
| 17 | Body | 471430 | 1 | |
| 18 | Sealing washer | 477016 | 1 | |
| 19 | Wear washer | 843927 | 1 | |
| 20 | Bearing bushing | 477012 | 1 | Earl. pr. repl by 477160 |
| 21 | Slide bearing | 477160 | 1 | |
| 22 | Hexagon screw | 955353 | 1 | |
| 23 | Washer | 960145 | 1 | Classed engine,spec.867117., Replaces earlier production spacer pin FIG.15., D70B spec. 867278 alt. |
| 24 | Shaft | 471317 | 1 | |
| 25 | Sealing ring | 471321 | 1 | |
| 26 | Hexagon nut | 971072 | 1 | Alt |
| 27 | Protecting casing | 471889 | 1 |
| Item | Part Name | Part No. |
| 21 | Slide bearing 477160 | 477160 |
| Details | |
| Engine model | TD610G, TWD610G, TD710G, TWD710G, TAD730G, TWD740GE, TAD740GE, TAD741GE TD610M, TD630ME, TWD630ME, TD730ME, TWD730ME, TWD731ME TD610V, TWD610V, TD630VE, TWD630VE, TD640VE TD61A, TD61AW, TD61ACE, TD61AG, TD61AGP, TD61AP, TD61APB, TID61AG, TD71A, TD71AW, TD71ACE, TD71AG, TD71AGP, TD71AP, TD71APB, TID71A, TID71AG, TID71AGP, TID71AP, TID71APB, TID61AGP TD71A, TID71A, TWD710V, TD730VE, TWD731VE, TAD730V, TWD740VE TWD610P, TWD610PB, TWD710P, TWD710PB, TAD730P |
| Application | Automatic Belt Tensioner and Installation Components Belt Tensioner Device |
| Specification | |
| Descriptions | Late type |
Tags: Slide bearing, Volvo Penta, 477160
