Spacer sleeve 467347
| No. | Part Name | Part Number | Qty | Description |
| 1 | Bearing housing | 421074 | 1 | |
| 2 | Sealing ring | 424580 | 1 | (941580) |
| 3 | Shaft | 422073 | 1 | |
| 4 | Ball bearing | 11013 | 1 | |
| 5 | Spacer sleeve | 467347 | 1 | |
| 6 | Ball bearing | 181577 | 1 | |
| 7 | Washer | 423074 | 1 | |
| 8 | Hexagon screw | 940100 | 6 | |
| 9 | Lock washer | 421415 | 3 | |
| 10 | Pin | 950586 | 1 | |
| 11 | Woodruff key | 422329 | 1 | |
| 12 | Gear | 421079 | 1 | |
| 13 | Hexagon screw | 102056 | 3 | |
| 14 | Lock washer | 467052 | 1 | |
| 15 | Washer | 467055 | 3 | |
| 16 | Sealing ring | 423123 | 1 | |
| 17 | Hexagon screw | 955525 | 4 | |
| 17 | Hexagon screw | 955527 | 1 | |
| 18 | Spring washer | 941907 | 5 | |
| 19 | Gasket | 422130 | 1 | |
| 20 | Stud | 953224 | 2 | |
| 21 | Hexagon nut | 955825 | 2 | Late type |
| 22 | Spring washer | 941906 | 2 | |
| 23 | Cover | 422643 | 1 | |
| 24 | Companion flange | 422184 | 1 | |
| 25 | Spacer | 471368 | 1 | (421188 |
| 26 | Companion flange | 422461 | 1 | |
| 26 | Companion flange | 467471 | 1 | Replaced by 1pc 422461 carrier, 3PCS 417512 clutch plate, 2pcs 417514 washer, 2pcs 422469 screw and 2pcs 422187 plate. |
| 27 | Dog clutch disc | 417512 | 3 | |
| 28 | Hexagon screw | 955675 | 2 | |
| 29 | Hexagon screw | 422469 | 2 | |
| 30 | Hexagon screw | 955676 | 2 | |
| 31 | Nut | 422187 | 6 | |
| 32 | Washer | 417514 | 6 | |
| 33 | Washer | 940097 | 2 | |
| 34 | Hexagon screw | 940160 | 1 | SAE1-2 |
| 35 | Washer | 955896 | 1 | D70B spec. 867054, 867055, 867061, 867062, 867063, 867132, TD70B spec. 867065. |
| 36 | Pump companion guard | 822876 | 1 | |
| 37 | Washer | 955894 | 1 |
| Item | Part Name | Part No. |
| 5 | Spacer sleeve 467347 | 467347 |
| Details | |
| Engine model | D70CHC, D70CRC, TD70CHC, TD70CRC TAD120BHC |
| Application | Drive Device, Fuel Injection Pump Drive Device, Fuel Injection Pump: D |
