Spring 864927
| No. | Part Name | Part Number | Qty | Description |
| 1 | Smoke limiter | 862468 | 1 | |
| 3 | Plug | 244092 | 1 | |
| 4 | Gasket | 18840 | 1 | Spec.867473 alt |
| 5 | Spring | 837741 | 1 | |
| 6 | Bushing | 244672 | 1 | |
| 7 | Spring | 864927 | 1 | (864127) |
| 8 | Shaft | 848744 | 1 | |
| 9 | Washer | 847418 | 1 | |
| 10 | Diaphragm | 847417 | 1 | |
| 11 | Washer | 847418 | 1 | |
| 12 | Spring washer | 240769 | 1 | |
| 13 | Hexagon nut | 940197 | 1 | |
| 14 | Pin | 847421 | 1 | |
| 15 | Nut | 845426 | 1 | |
| 16 | Cover | 244678 | 1 | |
| 17 | Spring washer | 941906 | 6 | |
| 18 | Cross recessed screw | 956092 | 1 | (241793) |
| 19 | Screw | 848747 | 1 | |
| 20 | Screw | 847420 | 3 | |
| 21 | Screw | 848745 | 1 | |
| 22 | Cover | 848746 | 1 |
| Item | Part Name | Part No. |
| 7 | Spring 864927 | 864927 |
| Details | |
| Application | Smoke Eliminator: 862468 Smoke Eliminator: 862469 |
| Specification | |
| Descriptions | (862471) (864127) |
Related Products
Tags: Spring, Volvo Penta, 864927
