Suction pipe 824156
| No. | Part Name | Part Number | Qty | Description |
| 1 | Oil pump | 468023 | 1 | Repl by 468351 |
| 1 | Oil pump | 468351 | 1 | MO16911/XXXXX- |
| 2 | Tab washer | 190529 | 2 | |
| 3 | Hexagon screw | 955538 | 4 | |
| 4 | Suction pipe | 824156 | 1 | |
| 5 | Bracket | 896682 | 1 | |
| 6 | Wire gauze | 414621 | 1 | |
| 7 | Retaining ring | 118125 | 1 | |
| 8 | O-ring | 949658 | 1 | (925061) early type |
| 9 | Hexagon screw | 955531 | 2 | Late type |
| 10 | Spring washer | 941907 | 2 | |
| 11 | Service kit | 468036 | 1 | Incl in gasket kit 875399 (compression 8,4:1)., Early type |
| 12 | O-ring | 949657 | 1 | (925060) |
| 13 | Hexagon screw | 955533 | 2 | For engine with 40° angle of inclination, L=102mm |
| 13 | Hexagon screw | 959793 | 2 | |
| 14 | Spring washer | 941907 | 2 | |
| 15 | Fitting | 466908 | 1 | |
| 16 | Stud | 953235 | 2 | |
| 17 | Hexagon nut | 955826 | 2 | |
| 18 | Washer | 955894 | 4 | |
| 19 | Hexagon screw | 940113 | 2 | |
| 20 | Spring washer | 941907 | 4 | |
| 21 | Crankcase | 822586 | 1 | |
| 22 | Magnetic plug | 951906 | 1 | |
| 23 | Gasket | 470133 | 1 | (423365) |
| 24 | Hex. socket screw | 956570 | 43 | |
| 25 | Spring washer | 941907 | 43 | |
| 26 | Oil dipstick | 822542 | 1 | |
| 27 | Tube | 785606 | 1 | |
| 28 | Reduction valve | 468138 | 1 | |
| 29 | O-ring | 949721 | 1 | (925062) |
| 30 | Spring washer | 941906 | 2 | |
| 31 | Hexagon screw | 940100 | 2 | |
| 32 | Cover | 822587 | 2 | |
| 33 | Hatch | 822588 | 1 | |
| 34 | Gasket | 822589 | 3 | |
| 35 | Pipe | 896775 | 1 | |
| 36 | Hexagon screw | 955525 | 2 | |
| 37 | Spring washer | 941907 | 2 | |
| 38 | Gasket | 802287 | 1 | |
| 39 | Hexagon screw | 955535 | 30 | |
| 40 | Spring washer | 942336 | 30 | |
| 41 | Intermediate pipe | 824174 | 1 | |
| 42 | O-ring | 949658 | 1 | (925061) early type |
| 43 | Hexagon screw | 940135 | 2 | |
| 44 | Spring washer | 941907 | 2 | |
| 45 | Oil filter housing | 423064 | 1 | |
| 47 | Oil filter | 4785974 | 2 | |
| 48 | Nipple | 423067 | 2 | |
| 49 | Plug | 192114 | 2 | |
| 50 | Gasket | 957185 | 2 | |
| 51 | O-ring | 949657 | 1 | (925060) |
| 52 | O-ring | 925069 | 1 | |
| 53 | Hexagon screw | 955543 | 2 | |
| 54 | Hexagon screw | 955535 | 1 | |
| 55 | Washer | 940097 | 3 | |
| 56 | Spring washer | 942336 | 1 | |
| 58 | Oil pressure pipe | 470264 | 1 | Late type |
| 59 | Flange | 470262 | 1 | Late type |
| 60 | Sealing ring | 470263 | 1 | Late type |
| 61 | Bracket | 470143 | 1 | Late type |
| 62 | Flange screw | 942402 | 2 | |
| 63 | Clamp | 949786 | 1 | Late type |
| 64 | Washer | 955894 | 1 | |
| 65 | Flange screw | 942402 | 1 | |
| 66 | Lock nut | 945467 | 1 | Late type |
| Item | Part Name | Part No. |
| 4 | Suction pipe 824156 | 824156 |
| Details | |
| Engine model | D120A, TD120A TAD120AHC TAD120BHC TAD120CHC TD100CHC TD100CRC TD100G TD100G-85 TD100G-87 TD100GG TD100GG-85 TD100GG-87 TD100GP TD100GP-85 TD100HP-87 TD100HPB-87 TD1010G, TWD1010G TD120AHC TD120ARC TD120BHC TD120BRC TID100K TID100K-87 TID100KG TID100KG-87 TID100KGP-87 TID100KP TID100KP-87 TID100KPB-87 |
| Application | Lubricating System Lubricating System, Classed Engine Lubricating System, Standard: A Lubricating System, Standard: B Lubricating System, Standard: C Lubricating System, Standard: TD100GGP-87 Lubricating System: A Lubricating System: B Lubricating System: C Lubricating System: D |
