Tensioner 1545307
| No. | Part Name | Part Number | Qty | Description |
| 1 | Alternator | 872021 | 1 | For 24V electric system., 28V 60A, repl by 873757 |
| 2 | Support plate | 1082911 | 1 | |
| 3 | Tensioner | 1545307 | 1 | |
| 4 | Flange screw | 966365 | 1 | |
| 5 | Pulley | 822573 | 1 | |
| 6 | V-belt | 966798 | 1 | |
| 7 | Tensioning loop | 466734 | 1 | |
| 8 | Hexagon screw | 955299 | 1 | |
| 9 | Spring washer | 941907 | 1 | |
| 10 | Washer | 191172 | 1 | Spec.867054, 867221. |
| 11 | Hexagon screw | 955541 | 1 | |
| 12 | Hexagon screw | 940162 | 2 | MO-XXXXX/105194 |
| 13 | Spring washer | 942336 | 3 | |
| 14 | Spring washer | 941911 | 1 | |
| 1A | Fan | 847707 | 1 | Included in alternator |
| Item | Part Name | Part No. |
| 3 | Tensioner 1545307 | 1545307 |
| Details | |
| Engine model | TAD1030P TD1030ME, TWD1030ME |
| Application | Alternator, Low-Left Mounted Alternator, Low-Left Mounted: 55A Alternator, Low-Left Mounted: 60A Alternator, Low-Left Mounted: 80A Alternator, Twin, Low L/R |
