Turbocharger 3802191
| No. | Part Name | Part Number | Qty | Description |
| 1 | Turbocharger | 3802191 | 1 | |
| 1 | Turbocharger | 24426737 | 1 | |
| 2 | Return line | 20580172 | 1 | |
| 3 | Return line | 20580170 | 1 | |
| 4 | Plane gasket | 20405790 | 2 | |
| 5 | Flange screw | 984734 | 1 | |
| 6 | O-ring | 20405822 | 2 | |
| 7 | Retainer | 20405789 | 1 | |
| 8 | Flange screw | 20405792 | 1 | |
| 9 | Stud | 20412318 | 4 | |
| 10 | Hexagon nut | 20517048 | 4 | |
| 11 | Hexagon screw | 20405609 | 4 | |
| 12 | Gasket | 20795122 | 1 | |
| 13 | Flange | 20405607 | 1 | |
| 14 | Gasket | 20405590 | 1 | |
| 15 | Exhaust pipe | 20580164 | 1 | |
| 16 | Stud | 20405587 | 8 | |
| 17 | Gasket | 20557208 | 1 | |
| 18 | Washer | 20799731 | 8 | |
| 19 | Nut retainer | 20505959 | 8 | (20405593) |
| 20 | Oil line | 20580165 | 1 | |
| 21 | Gasket | 969011 | 4 | |
| 22 | Hollow screw | 25167 | 2 |
| Item | Part Name | Part No. |
| 1 | Turbocharger 3802191 | 3802191 |
| Details | |
| Engine model | TAD520GE TAD520VE TAD530GE, TAD531GE |
| Application | Exhaust Manifold and Turbocharger. High Mounted Turbo. Stage 2, Tier 2 Exhaust Manifold and Turbocharger. Low Mounted Turbo. Exhaust Outlet Front Exhaust Manifold and Turbocharger. Low Mounted Turbo. Exhaust Outlet Front. Stage 2, Tier 2 Exhaust Manifold and Turbocharger. Low Mounted Turbo. Stage 1, Tier 1 Exhaust Manifold and Turbocharger. Low Mounted Turbo. Stage 2, Tier 2 |
