Turbocharger 846634
| No. | Part Name | Part Number | Qty | Description |
| 1 | Turbocharger | 846634 | 1 | Repl by 847827 |
| 1 | Turbocharger | 3802066 | 1 | E.U=3803135, (863501) |
| 2 | Gasket | 470939 | 1 | Included in gasket kit for connecting of turbocharger. |
| 3 | Stud | 468891 | 4 | |
| 4 | Hexagon nut | 191894 | 4 | |
| 5 | Spacer sleeve | 470467 | 4 | |
| 6 | Lock washer | 468219 | 4 | |
| 7 | Oil pipe | 847262 | 1 | (423395) |
| 8 | Plane gasket | 420641 | 1 | |
| 9 | Hex. socket screw | 956584 | 1 | L=25mm |
| 10 | Hex. socket screw | 956585 | 1 | L=32mm |
| 11 | Spring washer | 942336 | 2 | |
| 12 | Hollow screw | 942007 | 1 | (954394) |
| 13 | Gasket | 11998 | 1 | |
| 14 | Gasket | 942703 | 1 | |
| 15 | Clamp | 968200 | 1 | |
| 16 | Hexagon screw | 955534 | 1 | |
| 17 | Oil return pipe | 849652 | 1 | |
| 19 | Spring washer | 942336 | 2 | |
| 20 | Gasket | 1543360 | 1 | |
| 21 | Hose | 466328 | 1 | |
| 22 | Hose clamp | 994559 | 2 | |
| 23 | Nipple | 941875 | 1 | |
| 24 | Gasket, plug | 18677 | 1 | |
| 25 | Cross recessed screw | 950046 | 1 | |
| 26 | Washer | 955893 | 1 | |
| 27 | Bracket | 468850 | 1 | |
| 28 | Clamp | 952632 | 1 | Late type |
| 29 | Spring washer | 941906 | 1 | |
| 30 | Hexagon nut | 955825 | 1 | Late type |
| 31 | Hose | 944378 | 1 | L=60mm |
| 32 | Gasket kit | 876352 | 1 | See group 99 |
| 32 | Hose clamp | 943482 | 2 | (951798) |
| Item | Part Name | Part No. |
| 1 | Turbocharger 846634 | 846634 |
| Details | |
| Engine model | TD120G TD120HPP TD121G |
| Application | Turbo TURBO AND INSTALLATION COMPONENTS Turbo and Installation Components: A |
| Specification | |
| Descriptions | MO62793/XXXXX- Repl by 847827 |
