Turbocharger 847860
| No. | Part Name | Part Number | Qty | Description |
| 1 | Turbocharger | 847860 | 1 | SN XXXXXXXXXX/16449- |
| 1 | Turbocharger | 3802069 | 1 | (847860) |
| 3 | Clamp | 1696912 | 1 | |
| 4 | Hexagon nut | 1695714 | 1 | (420473) |
| 7 | Impeller | 862238 | 1 | |
| 8 | Diffuser | 1696913 | 1 | |
| 10 | Nut | 1696673 | 1 | |
| 11 | Screw | 1696914 | 4 | |
| 14 | Splash plate | 1695972 | 1 | |
| 17 | Thrust collar | 1696679 | 1 | |
| 20 | Heat shield | 1696908 | 1 | |
| 22 | Screw | 1695980 | 4 | |
| 24 | Turbine rotor | 1696910 | 1 | |
| 25 | Plate | 1696666 | 2 | |
| 26 | Striker plate | 1696668 | 2 | |
| 28 | Gasket | 421324 | 1 | |
| 29 | Plane gasket | 420641 | 1 | |
| 30 | Repair kit | 275949 | 1 | See group 10A |
| 30 | Plane gasket | 420643 | 1 |
| Item | Part Name | Part No. |
| 1 | Turbocharger 847860 | 847860 |
| Details | |
| Engine model | TID71A TID71AG TID71AP |
| Application | Turbocharger and Installation Components Turbocharger with Installation Components Turbocharger: 847860 |
| Specification | |
| Descriptions | SN XXXXXXXXXX/16449- |
