V-belt 20797199
| No. | Part Name | Part Number | Qty | Description |
| 1 | Alternator, exch | 3803512 | 1 | |
| 1 | Alternator, exch, 28V 35A | 3803969 | 1 | (20412735) |
| 1 | Alternator | 20412735 | 1 | |
| 1 | Alternator, 28V 35A | 20584337 | 1 | (20412735) |
| 2 | Fan | 20798465 | 1 | |
| 3 | Mounting kit | 22467816 | 1 | |
| 4 | Spacer | 20798346 | 1 | |
| 5 | Washer | 20539564 | 1 | |
| 6 | Hexagon nut | 20441521 | 1 | |
| 7 | Voltage regulator | 20412578 | 1 | For 20412735 |
| 7 | Voltage regulator | 20797555 | 1 | |
| 8 | V-belt pulley | 20799510 | 1 | Later production |
| 9 | Pulley | 20798454 | 1 | (20798216) |
| 10 | Pulley | 20798454 | 1 | (20798216) |
| 11 | Bracket | 20459033 | 1 | |
| 12 | Flange screw | 984741 | 1 | L=70mm |
| 13 | Hexagon screw | 20540915 | 4 | |
| 14 | Lock band | 20795935 | 1 | Later production |
| 15 | Lock piece | 20798373 | 1 | Later production |
| 16 | Washer | 20460127 | 1 | |
| 17 | Hexagon screw | 20516135 | 1 | |
| 18 | Flange screw | 984735 | 1 | |
| 19 | Washer | 20460365 | 1 | |
| 20 | Flange screw | 20405504 | 1 | |
| 21 | V-belt | 20797199 | 1 | L=785mm, B=11mm |
| 23 | Tensioner | 20405804 | 1 | SN-1025582 |
| 24 | Washer | 20405802 | 1 | |
| 25 | Hexagon nut | 20501349 | 1 |
| Item | Part Name | Part No. |
| 21 | V-belt 20797199 | 20797199 |
| Details | |
| Engine model | TAD520VE, TAD720VE, TAD721VE, TAD722VE TAD721GE, TAD722GE TAD732GE, TAD733GE |
| Application | Alternator, High Mounted Right Side (1) 14V 95A / 28V 55A: 14V/95A Alternator, High Mounted Right Side (1) 14V 95A / 28V 55A: 28V/55A Alternator, High Mounted Right Side 14V 55A Alternator, High Mounted Right Side 28V 35A |
| Specification | |
| Descriptions | For fan at separate fan bracket., L=785mm L=785mm, B=11mm |
