V-belt 978564
| No. | Part Name | Part Number | Qty | Description |
| 1 | Alternator | 872021 | 1 | For 24V electric system., 28V 60A, repl by 873757 |
| 3 | Pulley | 822573 | 1 | |
| 4 | V-belt | 978547 | 1 | |
| 5 | Bracket | 3825163 | 1 | |
| 6 | Flange screw | 966367 | 1 | M14X100 |
| 7 | Spacer sleeve | 1675685 | 1 | |
| 8 | Hexagon nut | 971071 | 1 | |
| 9 | Hexagon screw | 955537 | 3 | |
| 10 | Spacer sleeve | 823575 | 3 | AQ115A MOXXXX/86909-., Repl by 1pc 840539 bracket (8 holes), 9PCS 941907 6PCS 9552 97, 2pcs 955298., Late type |
| 11 | Tensioner | 966797 | 1 | |
| 12 | Hexagon screw | 955541 | 1 | |
| 13 | Spring washer | 942336 | 1 | |
| 14 | Tensioning loop | 466734 | 1 | |
| 15 | Hexagon screw | 955299 | 1 | |
| 16 | Spring washer | 941907 | 1 | |
| 17 | Washer | 191172 | 1 | Spec.867054, 867221. |
| 18 | Alternator | 872021 | 1 | For 24V electric system., 28V 60A, repl by 873757 |
| 20 | Pulley | 822573 | 1 | |
| 21 | V-belt | 978564 | 1 | |
| 22 | Bracket | 3825849 | 1 | |
| 23 | Bushing | 831920 | 1 | |
| 24 | Spring pin | 1610144 | 2 | |
| 25 | Hexagon screw | 971003 | 1 | |
| 26 | Spring washer | 941911 | 1 | |
| 27 | Hexagon screw | 955538 | 2 | |
| 28 | Washer | 940097 | 2 | |
| 29 | Tensioner | 863726 | 1 | |
| 30 | Tensioning loop | 466734 | 1 | |
| 31 | Hexagon screw | 955542 | 1 | |
| 32 | Hexagon screw | 955299 | 1 | |
| 33 | Washer | 191172 | 1 | Spec.867054, 867221. |
| 34 | Spring washer | 941907 | 1 | |
| 23A | Hexagon screw | 955555 | 1 | L=83mm |
| Item | Part Name | Part No. |
| 21 | V-belt 978564 | 978564 |
| Details | |
| Engine model | TD100G-87 TD1030VE, TWD1031VE |
| Application | Alternator, Twin, Low L/R Alternator, Twin, Low L/R, SNXXXXXXXXXX/268617- |
| Specification | |
| Descriptions | (966926) |
Related Products
Tags: V-belt, Volvo Penta, 978564
