V-ribbed belt 20997774
| No. | Part Name | Part Number | Qty | Description |
| 1 | Alternator | 21429786 | 1 | 28V 110A |
| 2 | Bracket | 3829091 | 1 | |
| 3 | Flange screw | 984738 | 1 | |
| 4 | Flange screw | 984752 | 1 | |
| 5 | Insulating bushing | 21308514 | 2 | |
| 6 | Flange lock nut | 990950 | 1 | |
| 7 | V-ribbed belt | 20464710 | 1 | Without AC |
| 7 | V-ribbed belt | 20529243 | 1 | |
| 7 | V-ribbed belt | 20860536 | 1 | SN7011406195-, Used when AC-compressor is mounted., Use with belt tensioner 21819687 |
| 7 | V-ribbed belt | 20997774 | 1 | Used when AC-compressor is mounted. |
| 8 | Insulating bushing | 21328137 | 2 | |
| 9 | Flange screw | 984826 | 1 | |
| 10 | Flange nut | 990940 | 1 | |
| 11 | Bracket | 3839320 | 1 | |
| 12 | Flange screw | 984754 | 4 | |
| 13 | Belt tensioner | 21422767 | 1 | SN-7011406194 |
| 14 | Flange screw | 990862 | 1 | |
| 15 | Belt tensioner | 21819687 | 1 | SN7011406195- |
| 16 | Flange screw | 994395 | 1 | |
| 17 | Bracket | 22944743 | 1 | SN7011406195- |
| 18 | Flange screw | 984754 | 2 | |
| 19 | Wiring harness | 21952274 | 1 | Alternator-Starter, start/stop |
| 19 | Wiring harness | 22610305 | 1 | Alternator-Starter, Std |
| 20 | Flange lock nut | 990949 | 1 | |
| 21 | Hexagon nut | 983715 | 1 | (949578) |
| 22 | Hexagon nut | 983716 | 2 | |
| 23 | Cable tie | 948211 | 1 |
| Item | Part Name | Part No. |
| 7 | V-ribbed belt 20997774 | 20997774 |
| Details | |
| Engine model | TAD1140VE, TAD1141VE, TAD1142VE TAD1150VE, TAD1151VE, TAD1152VE TAD1170VE, TAD1171VE, TAD1172VE |
| Application | AC-Compressor Alternator,Belt Tensioner, Single Mounted Alternator. Extra. 28V/150A |
| Specification | |
| Descriptions | SN-7011406194, Used when AC-compressor is mounted., Use with belt tensioner 21422767 Used when AC-compressor is mounted. |
