Valve guide 21067953
| No. | Part Name | Part Number | Qty | Description |
| 0 | Gasket | 11994 | 2 | |
| 0 | Gasket | 11996 | 7 | |
| 0 | Gasket | 11998 | 5 | |
| 0 | Gasket, plug | 18677 | 2 | |
| 0 | Gasket | 18813 | 1 | |
| 0 | Thrust washer kit | 270929 | 1 | Std D |
| 0 | Thrust washer kit | 270930 | 1 | O.S=0,10mm |
| 0 | Thrust washer kit | 270931 | 1 | O.S=0,20mm |
| 0 | Thrust washer kit | 270932 | 1 | 0,30mm o.s |
| 0 | Plane gasket | 420641 | 1 | |
| 0 | Rubber moulding | 469601 | 1 | |
| 0 | Sealing ring | 469846 | 3 | |
| 0 | Gasket | 470993 | 1 | (420423) |
| 0 | Rubber moulding | 471708 | 1 | |
| 0 | O-ring | 943177 | 1 | |
| 0 | O-ring | 944126 | 1 | |
| 0 | Snap ring | 945483 | 2 | |
| 0 | Gasket | 947281 | 7 | |
| 0 | Gasket | 947627 | 2 | |
| 0 | Gasket | 947629 | 3 | |
| 0 | O-ring | 948980 | 1 | |
| 0 | O-ring | 949187 | 2 | |
| 0 | O-ring | 949647 | 2 | |
| 0 | O-ring | 949656 | 3 | |
| 0 | O-ring | 949659 | 3 | |
| 0 | O-ring | 949722 | 1 | |
| 0 | O-ring | 955982 | 6 | AQ120B excl USA MO85861850/XXXX-. BB140A MO85874155/XXXX-. AQ120B USA MO85885755/XXXX-. AQ145A MO85891625/XXXX-. |
| 0 | O-ring | 968208 | 1 | |
| 0 | Gasket | 969011 | 12 | |
| 0 | O-ring | 974673 | 1 | |
| 0 | O-ring | 975675 | 1 | |
| 0 | O-ring | 977030 | 1 | |
| 0 | Gasket | 979099 | 1 | |
| 0 | Gasket | 982721 | 2 | |
| 0 | O-ring | 984127 | 1 | |
| 0 | O-ring | 992065 | 2 | |
| 0 | Sealant | 1161231 | 1 | 304ml |
| 0 | Sealing ring | 1543578 | 1 | |
| 0 | Sealing ring | 1547252 | 3 | |
| 0 | Sealing ring | 1547255 | 1 | |
| 0 | Sealing ring | 1675066 | 1 | |
| 0 | Sealing ring | 1677370 | 2 | |
| 0 | Gasket kit, connection, turbo | 3589673 | 1 | |
| 0 | De-carbonizing kit, decarbonizing | 3589674 | 1 | |
| 0 | Overhaul gasket kit | 3589675 | 1 | |
| 0 | Camshaft | 3829188 | 1 | SN-2016010024 |
| 0 | Overhaul kit, cylinder head | 3840397 | 1 | SN-2016002476 |
| 0 | Gasket kit | 3886446 | 1 | |
| 0 | Overhaul kit, reconditioning | 3886448 | 1 | |
| 0 | Overhaul kit, cylinder head | 3886521 | 1 | SN2016002477- |
| 0 | Cylinder liner kit | 3886754 | 6 | |
| 0 | Valve seat | 3965955 | 12 | |
| 0 | Plane gasket | 3979639 | 2 | |
| 0 | Gasket | 4804167 | 1 | |
| 0 | Seal | 8131154 | 1 | |
| 0 | Valve seat | 8131798 | 12 | |
| 0 | Valve stem seal | 8131799 | 24 | |
| 0 | Seal | 8131970 | 2 | |
| 0 | Valve collet | 8170995 | 48 | |
| 0 | Sealing ring | 20381352 | 1 | For pipe 8131290 |
| 0 | Exhaust valve | 20513285 | 12 | |
| 0 | Sealing ring kit | 20520607 | 1 | See parts bulletin |
| 0 | Shim | 20523555 | 1 | TH=0,2mm |
| 0 | Shim | 20523556 | 1 | TH=0,3mm |
| 0 | Shim | 20523557 | 1 | TH=0,5mm |
| 0 | Sealing ring | 20526428 | 1 | |
| 0 | O-ring | 20536487 | 6 | |
| 0 | Sealing ring | 20551483 | 2 | |
| 0 | Valve guide | 20562837 | 24 | Replaced by 21067953 |
| 0 | Seal | 20563945 | 1 | |
| 0 | Valve seat, exhaust | 20564028 | 12 | |
| 0 | Main bearing kit | 20578851 | 6 | SN002477-., Std |
| 0 | Main bearing kit | 20578853 | 1 | SN002477- Bearing no 7., Std |
| 0 | Sealing ring | 20579690 | 1 | |
| 0 | Big-end bearing kit | 20586602 | 6 | Std |
| 0 | Big-end bearing kit | 20586603 | 6 | O.S=0,25mm |
| 0 | Big-end bearing kit | 20586604 | 6 | O.S=0,50mm |
| 0 | Big-end bearing kit | 20586605 | 6 | O.S=0,75mm |
| 0 | Big-end bearing kit | 20586606 | 6 | O.S=1,00mm |
| 0 | Big-end bearing kit | 20586607 | 6 | O.S=1,25mm |
| 0 | Main bearing kit | 20700881 | 6 | SN002477-., O.S=0,25mm |
| 0 | Main bearing kit | 20700882 | 6 | SN002477-., O.S=0,50mm |
| 0 | Main bearing kit | 20700885 | 6 | SN002477-., O.S=0,75mm |
| 0 | Main bearing kit | 20700886 | 6 | SN002477-., O.S=1,00mm |
| 0 | Main bearing kit | 20700887 | 6 | SN002477-., O.S=1,25mm |
| 0 | Main bearing kit | 20700890 | 1 | SN002477- Bearing no 7., O.S=0,25mm |
| 0 | Main bearing kit | 20700891 | 1 | SN002477- Bearing no 7., O.S=0,50mm |
| 0 | Main bearing kit | 20700892 | 1 | SN002477- Bearing no 7., O.S=0,75mm |
| 0 | Main bearing kit | 20700893 | 1 | SN002477- Bearing no 7., O.S=1,00mm |
| 0 | Main bearing kit | 20700895 | 1 | SN002477- Bearing no 7., O.S=1,25mm |
| 0 | Valve seat, intake | 20709467 | 12 | SN-2016074098 |
| 0 | Sealing ring | 20723207 | 1 | |
| 0 | Cylinder head gasket | 20725045 | 1 | SN2016010025- Replaced by 21313541 |
| 0 | Sealing strip | 20734156 | 1 | |
| 0 | Inlet valve | 20735572 | 12 | |
| 0 | Sealing strip | 20736230 | 1 | |
| 0 | Inlet valve | 20739057 | 12 | |
| 0 | Plane gasket | 20784537 | 1 | |
| 0 | Sealing ring | 20799996 | 1 | (425137) |
| 0 | Sealing strip | 20815558 | 1 | |
| 0 | Piston ring kit | 20819869 | 1 | |
| 0 | Sealing ring | 20852762 | 4 | |
| 0 | Sealing ring | 20852764 | 14 | |
| 0 | Sealing ring | 20852765 | 22 | |
| 0 | Rocker arm, intake | 20888104 | 6 | SN-2016010024 Ceramic roller |
| 0 | Camshaft | 20894565 | 1 | SN2016010025- |
| 0 | Sealing kit | 20938964 | 2 | (20883460), For 11447007 |
| 0 | Camshaft bearing kit | 21006103 | 6 | |
| 0 | Camshaft bearing kit | 21006109 | 1 | |
| 0 | Bearing housing, rear | 21042355 | 1 | |
| 0 | Valve guide | 21067953 | 24 | |
| 0 | Overhaul kit, camshaft, rocker arms | 21160724 | 1 | SN-2016010024 |
| 0 | Overhaul kit, camshaft, rocker arms | 21160725 | 1 | SN2016010025- |
| 0 | Rocker arm, fuel injector | 21160989 | 6 | |
| 0 | Seal | 21185132 | 2 | |
| 0 | Cylinder liner kit | 21254035 | 6 | |
| 0 | Washer | 21261987 | 1 | |
| 0 | Rocker arm, exhaust | 21282816 | 6 | |
| 0 | Rocker arm, intake | 21282818 | 6 | SN2016010025- Ceramic roller |
| 0 | Gasket | 21352841 | 6 | (8131215) |
| 0 | Rubber moulding | 21415427 | 1 | |
| 0 | Connection pipe | 21420336 | 1 | |
| 0 | Sealing ring | 21423788 | 1 | For pipe 21420336 |
| 0 | Gasket | 21497512 | 1 | |
| 0 | Sealing strip | 21513804 | 1 | |
| 0 | Sealing ring | 21780376 | 4 | |
| 0 | Crankshaft seal | 85108352 | 1 | |
| 0 | Copper sleeve kit | 85124276 | 6 |
| Item | Part Name | Part No. |
| 0 | Valve guide 21067953 | 21067953 |
| Details | |
| Engine model | TAD1640GE, TAD1641GE, TAD1642GE TAD1641GE, TAD1642GE, TAD1650GE, TAD1651GE TAD1641VE, TAD1642VE TAD1643VE-B TAD1650VE TAD1650VE-B, TAD1651VE TAD1660VE, TAD1661VE, TAD1662VE, TAD1640VE-B, TAD1641VE-B, TAD1642VE-B TAD1670VE, TAD1671VE, TAD1672VE |
| Application | Cylinder Head Cylinder Head SN-2016010024 Cylinder Head Standard Cylinder Head with VCB Cylinder Head, internal EGR Repair Kits |
| Specification | |
| Descriptions | (20916916) |
