Washer 192287
| No. | Part Name | Part Number | Qty | Description |
| 1 | Fan protector | 823114 | 1 | Classified engine |
| 3 | Cross recessed screw | 955137 | 2 | Spec. 867055., Replaced by later production., Early type |
| 4 | Washer | 192287 | 2 | Spec. 867055., Replaced by later production., Early type |
| 5 | Hexagon screw | 955511 | 1 | TD CO gear |
| 6 | Spring washer | 941906 | 1 | |
| 8 | Hexagon screw | 940098 | 2 | |
| 9 | Spring washer | 942336 | 2 | |
| 10 | Hexagon screw | 940133 | 2 | |
| 11 | Hexagon nut | 955827 | 2 | AQ115A MOXXXX/86909-., Repl by 1pc 840539 bracket (8 holes), 9PCS 941907 6PCS 9552 97, 2pcs 955298. |
| 12 | Spring washer | 942336 | 2 | |
| 14 | Washer | 940097 | 2 | |
| 15 | Hexagon screw | 955561 | 2 | |
| 16 | Spring washer | 940280 | 2 | |
| 17 | Hexagon screw | 940135 | 1 | |
| 18 | Spring washer | 941907 | 1 | |
| 19 | Spacer sleeve | 820506 | 1 | L=9mm |
| Item | Part Name | Part No. |
| 4 | Washer 192287 | 192287 |
| Details | |
| Engine model | D70B TAD120BHC TAD120CHC TD120BHC TD120BRC TD120G TD120GG TD120HPP TD70G TD70G-83 TID120FG TID120HPP TID70G |
| Application | Fan-and Belt Protection with Inst- Allation Components, Generator Fan-and Belt Protection with Installation Components Lubricating System Lubricating System, Angle of Inclination 10° Lubricating System, Angle of Inclination 40° Lubricating System, Angle of Inclination 40°: A Lubricating System, Angle of Inclination 40°: B Lubricating System, Standard Model Lubricating System, Standard Model: A Lubricating System, Standard Model: B Lubricating System: A Lubricating System: B Lubricating System: D |
| Specification | |
| Descriptions | (941906) Classified engine Spec. 867055., Replaced by later production., Early type |
