Washer 843422
| No. | Part Name | Part Number | Qty | Description |
| 1 | Turbocharger | 3802018 | 1 | |
| 3 | Rotor | 847634 | 1 | |
| 5 | Turbine | 1695431 | 1 | |
| 6 | Piston ring | 411794 | 2 | |
| 6 | Piston ring | 467555 | 1 | |
| 7 | Thrust ring | 467026 | 2 | |
| 8 | Spacer sleeve | 422660 | 1 | |
| 10 | Ring retainer | 467556 | 1 | |
| 11 | Lock ring | 417727 | 4 | |
| 12 | Sleeve | 843423 | 1 | |
| 14 | Splash plate | 422662 | 1 | |
| 15 | Insert | 467557 | 1 | |
| 17 | Lock ring | 420467 | 1 | |
| 18 | Compressor wheel | 847633 | 1 | |
| 19 | Nut | 1518784 | 1 | (422669) |
| 20 | Gasket | 417378 | 1 | |
| 21 | Gasket | 417381 | 1 | |
| 23 | Lock ring | 422360 | 1 | |
| 25 | Gasket | 417382 | 1 | |
| 26 | Screw | 845576 | 8 | |
| 27 | Washer | 843422 | 8 | |
| 28 | Screw | 420470 | 10 | |
| 29 | Spring washer | 411809 | 10 | |
| 30 | Washer | 1695715 | 5 | |
| 31 | Repair kit | 273356 | 1 | See group 10A |
| 31 | Striker plate | 843421 | 4 |
| Item | Part Name | Part No. |
| 27 | Washer 843422 | 843422 |
| Details | |
| Application | Turbo Turbo: 842427 Turbo: 844452 Turbo: 844549 Turbo: 845713 |
